In electrical engineering, VE is a term used to refer to voltage. Voltage is the difference in electric potential between two points, and it is measured in volts. The term VE is commonly used in electrical engineering to refer to the voltage between two specific points in a circuit. For example, the voltage across a component or the voltage between the ground and a specific point in a circuit. The term VE is also used to refer to the voltage level of a specific node or terminal in a circuit.
Explore related products
What You'll Learn
+ve and gate source voltage
In electrical engineering, the word "positive" is sometimes shortened to "+ve". This notation is used to indicate a positive gate source voltage. For example, the symbol "+ve" may be used to indicate a positive gate-source voltage in a MOSFET transistor.
A MOSFET (metal-oxide-semiconductor field-effect transistor) is a type of voltage-controlled device commonly used in electronic circuits. The gate-source voltage, denoted as VGS or VGS+, is an important parameter in the operation of MOSFETs. It refers to the voltage applied between the gate and source terminals of the transistor.
The gate-source voltage plays a crucial role in determining the conductivity of the channel between the source and drain terminals of the MOSFET. By applying a positive voltage to the gate terminal, a vertical electric field is generated, which controls the amount of charge and conductivity of the channel. This process is known as accumulation or depletion of mobile charge carriers.
The gate-source voltage also influences the current flow at the gate terminal. In a typical field-effect transistor (FET), the gate potential varies the conductivity of the channel, and the current flow is regulated by applying a voltage between the source and drain terminals. The minimum gate-source voltage required to turn on the MOSFET is known as the gate threshold voltage (VTH). However, it's important to note that the MOSFET will not allow a large drain current to flow at this point.
The relationship between MOSFET gate voltage and source voltage is a topic of discussion among electrical engineers. Some engineers have expressed surprise at the lack of a higher voltage at the MOSFET source pin when using multiple voltage sources with a common ground. It's important to carefully consider the circuit design and voltage levels to ensure optimal performance and avoid issues such as voltage swings.
Understanding NC: Electrical Wiring and its Intricacies
You may want to see also
Explore related products
-ve and voltage negative
In electrical engineering, the term '-ve' is commonly used to refer to a negative voltage with respect to ground. Ground or 0V is typically the reference potential within a circuit. When you connect the "+" pole of a battery to the ground, the "-" pole of the battery becomes the negative pole with respect to the ground.
The terms Vdd and Vss are often used to refer to positive and negative voltages, respectively. Vdd is normally 3.3V or lower (1.8V or 1.2V), while Vss refers to zero volts. In some circuits, you will find pins Vss and Vdd instead of Vcc and Vee, which were commonly used in the past. The use of Vdd and Vss is derived from the binary notation system, where a single digit represents a power of 2, and the double letters ("dd" or "ss") indicate higher power levels.
In the context of MOSFET transistors, the term Ve refers to the gate source voltage when it is positive. The +" symbol already indicates that the voltage is positive, so the use of "+ve" is redundant, similar to how PIN is used as an acronym for "number", making "PIN number" redundant.
In circuits using bipolar junction transistors (BJTs), the negative supply voltage on the emitter side of an NPN-type transistor is referred to as "Vee". It is believed that the repetition of the letter "E" in "Vee" helps distinguish it from the emitter voltage (VE). Vee is typically directly connected to the emitter or connected through resistors or other means. In a single power supply system, Vee shares the same potential as ground. Circuits with multiple negative supply voltages may use labels like "Vee1" and "Vee2" to distinguish between them.
