In electrical engineering, the letter Z is used to symbolize impedance, which is a measure of the opposition to the flow of electric current in a circuit. Impedance is a complex number with the same units as resistance, the ohm, denoted by the Greek letter omega (Ω). The impedance of a two-terminal circuit element is the ratio of the complex sinusoidal voltage to the complex current flowing through it.
| Characteristics | Values |
|---|---|
| Full Form | Electrical Impedance |
| Symbol | Z |
| Unit | Ohm (Ω) |
| Formula | Z = V/I, where V = voltage (volts) and I = current (amperes) |
| Definition | Opposition to alternating current presented by the combined effect of resistance and reactance in a circuit |
| Calculation | Ratio of the complex representation of the sinusoidal voltage between its terminals, to the complex representation of the current flowing through it |
| Representation | Magnitude and phase in the polar form |
| Examples | Resistor: Z - 100Ω < 0◦, Inductor: Z - 100Ω < 90◦ |
Explore related products
![ANSI NOTICE Buried conduit [down arrow] Sign with Symbol Safety Warning Metal Tin Sign (12x16 Inches)](https://m.media-amazon.com/images/I/51n2UEJ6wpL._AC_UY218_.jpg)
What You'll Learn
Impedance in electrical engineering
Impedance, denoted as Z, is a fundamental concept in electrical engineering. It is the opposition or resistance to the flow of alternating current in an electrical circuit. Impedance is a vector (two-dimensional) quantity that consists of two independent scalar (one-dimensional) phenomena: resistance and reactance. Resistance is the real part of impedance, representing the measure of the extent to which a substance opposes the movement of electrons among its atoms, resulting in opposition to the flow of current. Materials with low resistance are known as electrical conductors, while those with high resistance are called insulators or dielectrics.
Reactance is the imaginary part of impedance, representing the extent to which an electronic component, circuit, or system stores and releases energy as the current and voltage fluctuate with each AC cycle. It is denoted as X and is expressed in ohms, just like resistance. However, unlike resistance, impedance is observed only in AC circuits and not in DC circuits.
The impedance of a two-terminal circuit element is the ratio of the complex representation of the sinusoidal voltage between its terminals to the complex representation of the current flowing through it. It can be represented as a complex number, with the same units as resistance, for which the SI unit is the ohm (Ω). Its magnitude and phase can be written in the polar form |Z|∠θ, but Cartesian complex number representation is often preferred for circuit analysis.
Impedance has numerous real-world applications in electrical engineering, such as filter design, power electronics, antenna design, and audio systems. In filter design, impedance controls the flow of current, allowing only specific frequencies to pass through. In power electronics, impedance regulates the flow of current for efficient circuit operation. Antenna design requires impedance matching to ensure maximum power transfer of signals. In audio systems, impedance is used to match amplifiers to speakers for optimal sound quality. Impedance is an essential concept in modelling AC circuits and plays a crucial role in various applications, from small signal designs in antennas to long-distance power transfer in transmission lines.
