Turn signals are an essential safety feature on vehicles, allowing drivers to communicate their intentions to other road users. The electrical components that communicate with turn signals include the turn signal switch, flasher relay, bulbs, wiring harness, fuses, and indicator lights. When the turn signal is activated, a current is sent through the bimetallic spring, causing it to heat up and bend, completing the circuit and sending a signal to the bulbs to flash. The ticking sound produced by the thermal flasher serves as a reminder for the driver that the signal is on. While newer vehicles may use an electronic flasher or chip-controlled system, the underlying principle of completing the circuit to activate the turn signals remains the same.
| Characteristics | Values |
|---|---|
| Turn signal switch | Allows current to flow through the filament of the lights when the turn-signal stalk is pushed down |
| Flasher relay | Used to manage the switch and complete the circuit |
| Bulbs | Flash when power is sent to the left or right turn-signal lights |
| Wiring harness | Ensures all wires are connected correctly to prevent electrical issues |
| Fuse | Protects the electrical circuit from excess current |
| Indicator lights | Lights on the dashboard that illuminate when the turn signal is activated |
| Ticking sound | Acts as a reminder for the driver that the signal is on |
| Self-canceling mechanism | Turns off the turn signal when the steering wheel is turned back after a turn |
Explore related products
What You'll Learn
Turn signal switch
Turn signals are an important communication tool that drivers depend on. While the concept of turn signals seems simple, there is some interesting technology at work. When you push the turn-signal stalk down, the thermal flasher connects to the turn-signal bulbs by way of the turn-signal switch, completing the circuit and allowing current to flow. The turn signal switch is an essential component in this process.
The turn signal switch is a small, cylindrical device that is usually located in the fuse panel under the dashboard of a car. It typically costs around $3 in auto parts stores and is known to work reliably for years. When you activate your turn signal, the power either stops in the switch or is sent to the left or right turn signal lights, including the indicator lights on the dashboard. The power then flows through the filament of the lights and is grounded.
In addition to the basic functionality of the turn signal switch, there are other mechanisms in place to enhance the turn signal system. For example, most cars have a self-cancelling mechanism that turns off the turn signal when you have finished making a turn. This mechanism works through a notched hub on the steering shaft that engages with the turn signal switch.
Over time, there have been improvements and variations in the design of turn signal switches and the overall turn signal system. Initially, mechanical turn signals produced a clicking sound, which served as an auditory indicator for the driver. However, modern electronic circuit designs have eliminated this sound, leading some manufacturers to consider customising the signal sound or incorporating smarter technology for automated signal cancellation.
