Pressure relief valves are crucial for maintaining system safety by releasing excess pressure from machines handling fluids or gases. They are spring-loaded and feature gradual opening and closing. They are actuated by the upstream pressure and are best used with incompressible fluids. There are two types of relief valves: adjustable and electronic. Adjustable relief valves allow pressure setting changes via the outlet port. Electronic relief valves are capable of zero leakage using electric controls that observe and regulate system pressure. Safety valves, on the other hand, are used for compressible fluids (gas and vapours) and are characterised by the rapid action of opening and closing.
| Characteristics | Values |
|---|---|
| Purpose | To protect the integrity of a system by releasing excess pressure during overpressure situations and avoiding catastrophic failure. |
| Function | Releases excess pressure from machines handling fluids or gases. |
| Types | Adjustable, Electronic, Direct-acting, Balanced pilot-operated, Remote-controlled, Electrical, Power-actuated, Temperature pressure-actuated, Safety, Safety relief. |
| Applications | Chemical, Petrochemical, Power, Oil and Gas industries, Steam plants, Nuclear power plants, Forced-flow steam generators, Vessels, Tanks, Heaters carrying hot fluids. |
| Advantages | Safeguards the system from overpressure, Prevents fluid loss, Minimizes damage to system components. |
| Design | Spring-loaded, gradual opening and closing, Activated by upstream pressure, Adjustable or non-adjustable spring, Simple disc resting on valve seat. |
| Installation | Location decided by Process Engineers, Requirements mentioned in P&ID, General guidelines available for special cases. |
| Standards | API 527, API 598, API 6D, API 600, API 621, ANSI temperature and pressure ratings. |
Explore related products
What You'll Learn
- Pressure relief valves are used to release excess pressure from a system
- They protect the integrity of a system by opening up to release pressure
- Relief valves are spring-loaded and feature gradual opening and closing
- Safety valves, on the other hand, have a rapid opening and closing action
- Power-actuated valves are controlled by an external power source like electricity
Pressure relief valves are used to release excess pressure from a system
Pressure relief valves are an incredibly useful and necessary mechanism found in a variety of applications. They are used to release excess pressure from a system during overpressure situations, thus avoiding catastrophic failure. They are designed to open at a predefined set pressure and discharge fluid until the pressure drops to acceptable levels. Once the excess pressure is removed, the valve closes again to prevent fluid loss.
There are two main types of relief valves: adjustable and electronic. Adjustable relief valves allow for pressure setting changes via the outlet port. Electronic relief valves, on the other hand, offer zero leakage with electric controls that monitor and regulate the system pressure. These valves are commonly used in close discharge systems. Safety valves, a type of electronic relief valve, are used for compressible fluids such as gas and vapours and are characterised by their rapid opening and closing action. They are widely used in steam plants for boiler overpressure protection.
Power-actuated pressure relief valves are controlled by an external power source such as electricity, water, or steam, which manages the opening and closing of the valve. Temperature and pressure-actuated relief valves, or T&P safety relief valves, are actuated by the temperature or pressure of the inlet side of the valve and are used to prevent temperature and pressure from rising above specified values. These valves are commonly used in vessels, tanks, and heaters carrying hot fluids.
Relief valves are also used in accumulator circuits, where they eliminate the need for electrical, high and low-pressure switches and a solenoid-operated dump valve to unload the pump. Pilot-operated relief valves (PORVs) are another type of relief valve that relieves by remote command from a pilot valve connected to the upstream system pressure.
Overall, pressure relief valves are an important process safety device, widely used in industries such as chemical, petrochemical, power, and oil and gas to protect equipment and ensure system integrity.
