In electrical terms, a 'common' can refer to a few different things depending on the context. In a basic electrical setup, a circuit is composed of hot wires, common wires, and ground wires. A common wire, also called a C-wire or neutral wire, completes the circuit initiated by a hot wire. It returns unused current to the source, ensuring continuity and preventing overloads. This is different from a 'ground' wire, which provides a safety route in case of electrical faults. In this context, 'common' implies an arbitrary voltage reference with no connotation about its voltage relative to the earth. In other contexts, 'common' can also refer to power routed to two or more devices or the terminals on a switch.
| Characteristics | Values |
|---|---|
| Definition | The term "common" can have two meanings. It can refer to either a neutral wire or a wire that is connected to more than one other wire. |
| Circuit reference node | Has a node voltage of 0V. All other node voltages are referenced to this node. |
| Source of electric charge | An 'infinite' source (or sink) for electric charge with an unchanging potential. |
| Grounding | "Ground" means that the node can and should be tied to the earth. "Common" implies an arbitrary voltage reference with no connotation about its voltage relative to earth. |
| Function | Returns unused current to the source, ensuring continuity. |
| Safety | Prevents overloads and safeguards your home from potential hazards. |
| Identification | In most homes, the common wire color is white. In some cases, it may be labeled or marked differently, e.g., gray or blue. |
Explore related products
What You'll Learn
'Common' can refer to a neutral wire
In electrical terms, the word "common" can refer to a neutral wire, which is typically white or grey in colour. This wire is an essential component of a circuit, ensuring the proper operation of appliances and preventing malfunctions by balancing electrical flow and guarding against surges. It completes the circuit initiated by a hot wire, which carries the current to power appliances. The common wire returns unused current to the source, ensuring continuity and preventing overloads.
The term "common" in this context can also refer to a wire that is connected to more than one other wire. This could mean that the wire is connected to multiple devices or that it is used in both positions of a switch that switches two ways.
It is important to distinguish the common wire from the ground wire, which provides a safety route in case of electrical faults and is typically green or made of bare copper. While the common wire is associated with an arbitrary voltage reference, the ground wire is tied to the earth and has a node voltage of 0V.
In summary, the common wire, or neutral wire, plays a crucial role in ensuring the safe and efficient operation of electrical circuits and appliances in homes. It is identified by its colour, typically white or grey, and its function of returning unused current to the source.
