In electrical systems, a feeder is a power line that transmits electricity from a substation to different distribution points. It is a conducting device that supplies power to the branch circuits, which then connect to devices or equipment. Feeders are an important part of power distribution systems, ensuring electricity reaches its intended destinations. They are particularly crucial in public transportation systems, where they facilitate connectivity between high-capacity routes and more localized points, enabling seamless travel across regions. Feeder conductors are distinct from service conductors and branch circuit conductors, and their identification is crucial for qualified personnel to understand the electrical system.
Explore related products
What You'll Learn
Feeder vs. service and branch circuit conductors
A feeder is a circuit conductor that is neither a service conductor nor a branch circuit conductor. It is the middle set of conductors in the power distribution scheme. Feeder conductors deliver electricity within a house. They take over after the service entrance, bringing power from the utility pole, and supply power to the branch circuits.
Service conductors are the conductors from the service point to the service disconnect. They are the lines that run from the transformer secondary into the building's main service panel. Service conductors come ahead of feeders, and the essential difference is that you need the utility company to shut down the service to de-energize them.
Branch circuit conductors are the circuit conductors between the final overcurrent device protecting the circuit and the outlet(s). They connect the branch overcurrent device (e.g. branch breaker) to each load. Branch circuits can also connect to a daisy-chained group of loads, as is the case with receptacle and lighting circuits.
Feeder conductors are larger than branch circuit conductors and have higher current flows. They are also sized differently from branch circuit conductors. The size of a branch circuit conductor is determined by the OCPD size, whereas the size of a feeder conductor is determined by the total calculated load on the feeder.
A feeder diagram may be required prior to the installation of feeder conductors. This diagram should include the size and type of feeder conductors, the total calculated load on the feeder, and the rating of the feeder overcurrent protective devices.
