Mud rings are used to adapt 4 or 5 boxes to accept wiring devices. They are installed, and then the sheetrock is placed and cut for the smaller opening provided by the mud ring. Mud rings are used when mounting fixtures, and they hold the device in place. They are also used when there is no finished material on the wall, or the box is surface-mounted.
Explore related products
What You'll Learn
- Mud rings are used to adapt a 4 or 5 box to accept wiring devices
- They are installed before sheetrock, which is then cut for the smaller opening
- The front of the mud ring should be flush with the wall's finish surface
- A finish plate is put over the device after installing the mud ring
- There are two types of metal covers for electrical boxes
Mud rings are used to adapt a 4 or 5 box to accept wiring devices
A mud ring is used to adapt a 4" or 5" box to accept wiring devices. It is a raised device cover that fits onto a 4" square box, providing a greater volume for switch or receptacle installations. The mud ring is attached to the box, and the device is then installed onto the mud ring as if it were any other box. It is important that the front of the mud ring is flush with the finished surface of the wall.
After installing the mud ring, sheetrock is placed, and the rock is cut for the smaller opening provided by the mud ring. Any receptacles or switches can then be mounted in the mud ring, and a finish plate is put over the device. The finish plate has a small hole in the centre for the protruding front face of the receptacle. This allows for the replacement of the receptacle in the future without cutting into the wall.
Mud rings are particularly useful when there is no finished material on the wall, or when the box is surface-mounted. They are also used when the box is installed within a wall cavity, with the back of the cover plate flush with the outer surface of the panelling.
There are two types of metal covers for electrical boxes: Type One has a flat perimeter that touches the edges of the box, with the inner portion raised. Type Two is entirely raised, even along the outer perimeter where it sits on the edges of the box.
Mud rings are often used in conjunction with single-gang or double-gang cover plates, which provide access to the devices installed within the mud ring.
