An electronic flight instrument system (EFIS) is a flight deck instrument display system that displays flight data electronically instead of electromechanically. EFIS consists of a primary flight display (PFD), a multi-function display (MFD), and an engine-indicating and crew-alerting system (EICAS) display. EFIS improves display clarity by removing superfluous indications, such as the glide slope scale when not in use, and only displays parameters that exceed their limits. EFIS also colour-codes data, for example, a blue caption indicates the glide slope is armed, and it may change to green when captured. EFIS reduces the workload of pilots by providing all the required information on a single instrument.
| Characteristics | Values |
|---|---|
| Display technology | Electronic rather than electromechanical |
| Display units | Primary Flight Display (PFD), Multi-function Display (MFD), Engine Indicating and Crew Alerting System (EICAS) display |
| Display type | Cathode-ray tube (CRT), Liquid crystal display (LCD) |
| Features | Leads to the term "glass cockpit" |
| Display monitoring | Detect failures within the instrument system |
| Color-coding | Indicates changes in condition, e.g., blue for glide slope armed, green for glide slope capture, green needles for ground-based navigation, magenta needles for GPS navigation |
| Input validation | Verify that each sensor is providing valid data |
| Data comparison | Cross-check inputs from duplicated sensors |
| Flight director | Provides lateral and vertical guidance, reducing pilot workload |
| Primary Flight Display (PFD) | Integrates and depicts all information on a single display, typically placed centrally |
| Electronic Horizontal Situation Indicator (EHSI) | Replaces conventional instruments, depicts information such as Airborne Collision Avoidance System (ACAS) RA |
Explore related products
What You'll Learn
EFIS (Electronic Flight Instrument System)
An Electronic Flight Instrument System (EFIS) is a flight deck instrument display system that uses electronic display technology instead of electromechanical means. EFIS systems display all information critical to the flight, including calibrated airspeed, altitude, heading, attitude, vertical speed, and yaw. The use of electronic displays allows EFIS to use colour widely to indicate changes in conditions, such as a blue caption to indicate when the glide slope is armed, and green when captured.
EFIS systems consist of a primary flight display (PFD), a multi-function display (MFD), and an engine indicating and crew alerting system (EICAS) display. The PFD integrates and displays all information that was historically presented across several individual electromechanical instruments, improving the pilot's situational awareness and reducing the time needed to monitor the instruments. The PFD also alerts the aircrew to unusual or hazardous conditions by changing the colour or shape of the display or providing audio alerts.
The EFIS visual display is produced by the symbol generator, which receives data inputs from the pilot, signals from sensors, and EFIS format selections. The symbol generator performs the necessary computations, and the graphics generator and display driver produce the inputs to the display units.
Early EFIS models used cathode ray tube (CRT) displays, but modern systems use liquid crystal displays (LCD) which offer improved reliability, reduced weight and power consumption, and enhanced screen clarity and brightness.
