SPICE (Simulation Program with Integrated Circuit Emphasis) is a general-purpose, open-source analog electronic circuit simulator. It is a program used in integrated circuit and board-level design to check the integrity of circuit designs and predict circuit behavior. SPICE was developed at the Electronics Research Laboratory of the University of California, Berkeley, and has become the worldwide standard integrated circuit simulator. SPICE source files are commonly referred to as netlists, with each line in the file called a card. SPICE simulators can be used to perform digital simulation tasks and run logic simulations for digital circuits.
| Characteristics | Values |
|---|---|
| Full Form | Simulation Program with Integrated Circuit Emphasis |
| Developed by | Electronics Research Laboratory of the University of California, Berkeley |
| Developer | Laurence Nagel |
| Research Advisor | Prof. Donald Pederson |
| Based on | CANCER program |
| CANCER stands for | Computer Analysis of Nonlinear Circuits, Excluding Radiation |
| SPICE1 coded in | FORTRAN |
| SPICE2G.6 written in | C |
| SPICE source files | Netlists or Decks |
| File extension | .cir, .inp, .txt |
| SPICE output file | Text editing or word processing program |
| SPICE compatible | ngspice |
| SPICE simulation applications | Simulate electrical behavior of analog or mixed signal circuits |
