Electrical Noise In Flow Cytometry: Understanding The Basics

what is electrical noise in flow cytometry

Flow cytometry is a technology that characterises single extracellular vesicles (EVs) and analyses single cells in suspension at high speed. The cells are illuminated by a laser, and the emitted fluorescent light is collected through photoelectric devices. The photons are then converted to electric current, recorded, and analysed with dedicated computer software. The sensitivity and resolution of flow cytometers are functions of the signal produced by a given particle, as well as the noise in the presence of which the signal is detected. This noise is referred to as electrical noise, and it is influenced by various factors such as voltage, laser power, and detector efficiency. The characterisation of a cytometer's signal-to-noise ratio (SNR) and dynamic range (DNR) is essential for selecting the optimal voltage/gain for maximum efficiency and minimal electrical noise.

Characteristics Values
Definition Electrical noise in flow cytometry is the background noise produced by the instrument and the experimental conditions.
Factors Influencing Noise PMT voltage, thermionic noise, leakage current inside the PMT, photon current by scintillation from glass, field emission current, ambient electric fields, and cosmic rays.
Impact Electrical noise affects the sensitivity and resolution of flow cytometers, making it difficult to detect smaller particles like extracellular vesicles (EVs).
Optimization PMT voltage optimization aims to establish the optimum sensitivity of a flow cytometer for a given experiment by ensuring that autofluorescence is detected above the limit of sensitivity.
Techniques Well-defined scale calibration, using a precision light source like quantiFlashTM, can improve data acquisition and characterization of a cytometer's signal-to-noise ratio (SNR) and dynamic range (DNR).
Tools Software like BD Cytometer Setup and Tracking (CST) and BD FACSDivaTM can assist in optimizing and transferring PMT voltages for experiments.

shunzap

Signal-to-noise ratio (SNR) and dynamic range (DNR)

The signal-to-noise ratio (SNR) and dynamic range (DNR) are important parameters in flow cytometry that impact the accuracy and sensitivity of the instrument.

SNR is a measure that compares the level of the desired signal to the level of background noise or electrical noise. It is influenced by factors such as the emission of light, the detection by photoelectric devices, and the photoelectron quantum yield of the detector. A higher SNR indicates a stronger desired signal relative to the noise, improving the overall sensitivity of the instrument.

DNR, on the other hand, is a measure that compares the levels of the minimum detectable signal and the maximum detectable signal. It represents the range of signal intensities that the instrument can accurately detect. A higher DNR indicates a wider range of detectable signals, enhancing the instrument's ability to distinguish between weak and strong signals.

The relationship between SNR and DNR is important to consider. Increasing the SNR comes at the expense of DNR. This means that improving the sensitivity of the instrument by increasing the SNR may result in a narrower dynamic range. Therefore, finding the optimal balance between SNR and DNR is crucial to achieving the best instrument sensitivity.

To achieve this balance, well-defined scale calibration and PMT voltage optimization play a vital role. Calibration with a precision light source, such as quantiFlashTM, helps characterize the cytometer's response over the entire PMT voltage range. This allows for the selection of a voltage/gain corresponding to the PMT's maximum efficiency, resulting in the lowest electronic noise. Additionally, PMT voltage optimization techniques, such as setting the voltage based on the robust standard deviation of background electronic noise, help establish the optimum sensitivity for a given experiment.

By carefully considering SNR and DNR, and utilizing calibration and optimization techniques, flow cytometry instruments can be fine-tuned to provide accurate and sensitive data acquisition.

shunzap

Electrical noise and detector noise

Flow cytometry is a technology that characterises single extracellular vesicles (EVs) and detects cells. The electronics system in a flow cytometer is responsible for digitising and processing the photocurrent from the detector. Photons are converted to electrons, and the signal is multiplied proportionately. This signal exits the detector as an electric current (also known as a photocurrent) and enters the electronics system.

The photons that are emitted when the laser hits the cell as it passes through the interrogation point are detected by the photomultiplier (PMD) or photodiode (PD). These photons can come from light being scattered by the cell or by fluorescence emission of fluorophores associated with the cell. The electronics system acts as the brains of the flow cytometer, converting the photons to electrons, which are then converted from analogue to digitised data. The data is then ready for analysis.

Electrical noise in flow cytometry refers to the background noise in the presence of which a signal is detected. The noise is primarily due to the fact that the emission of light and its detection by photoelectric devices are stochastic processes. The magnitude of the signal, the background, and the photoelectron quantum yield of the detector limit the resolution and sensitivity of the flow cytometer.

Detector noise, or background noise, is the noise that is present in the absence of a signal. It is important to distinguish between the autofluorescence of unstained cells and detector noise. This is because, in order to distinguish a potentially weak fluorescent signal from background autofluorescence, it is necessary to be able to distinguish autofluorescence from detector noise. Detector noise can be influenced by various factors such as ambient electric fields, cosmic rays, thermionic noise, leakage current inside the PMT, photon current by scintillation from glass, and field emission current.

The amount of electronic noise needs to be measured since there is no predictable fixed value of dark current that can be read off the PMT's data sheet. The voltage/gain corresponding to a PMT's maximum efficiency can be selected to achieve the lowest electronic noise.

shunzap

Fluorescent particles and instrument sensitivity

Fluorescent particles are essential to flow cytometry, as they enable the detection of multiple fluorescence parameters for comprehensive cell characterization. Fluorophores, or "fluors", are attached to antibodies that recognize specific targets on or in cells. Each fluorophore has a unique peak excitation and emission wavelength, and the emission spectra often overlap. The choice of fluorophore depends on the wavelength of the laser used to excite the fluorochromes and the detectors available.

The detection efficiency (Q) of fluorescent particles is given as photoelectrons per fluorescence unit, such as the equivalent reference fluorophore (ERF) or MESF. Q is influenced by detector performance, laser power, optics, and the choice of target dye excitation efficiency. Low Q values can result from various factors, including low laser power, fluctuations in flow speed, and low detector efficiency.

The sensitivity of flow cytometers is influenced by the signal produced by a given particle and the noise present during detection. The noise arises due to the stochastic nature of light emission and detection by photoelectric devices. The magnitude of the signal, the background, and the photoelectron quantum yield of the detector determine the resolution and sensitivity of the cytometer.

To optimize the sensitivity of a flow cytometer, PMT voltage optimization is performed. The goal is to ensure that the autofluorescence of unstained cells is detected above the inherent limit of sensitivity of the detector. By setting the PMT voltage of unstained cells to 2.5-3.0 times the robust standard deviation (rSD) of the background electronic noise, the optimum PMT voltages can be established for a given analytical experiment.

The introduction of precision light sources, such as the quantiFlashTM, has enabled the characterization of a cytometer's signal-to-noise ratio (SNR) and dynamic range (DNR). This allows for the selection of voltage/gain corresponding to the maximum efficiency of the PMT, resulting in the lowest electronic noise and improved data acquisition.

Millions in India Still Without Power

You may want to see also

shunzap

Background noise and experimental conditions

Background noise in flow cytometry is influenced by a variety of factors, including the instrument's sensitivity, the voltage, and the experimental setup. The sensitivity of a flow cytometer is determined by the signal produced by a given particle and the noise present when the signal is detected. This noise is due to the stochastic nature of light emission and detection by photoelectric devices.

The voltage applied to the photomultiplier tubes (PMTs) also affects the amount of noise in the system. At any given voltage, there are different sources and amounts of dark current contributing to the noise, including thermionic noise, leakage current, photon current, and field emission current. These contributions vary non-linearly with voltage, so there is no fixed value for the dark current. For example, between 200 V and 700 V, leakage current dominates, while at higher voltages, thermionic noise becomes more significant.

The experimental setup can also introduce noise. For instance, in multicolor flow cytometry experiments, background noise can arise from Raman scatter and spillover spreading caused by other fluorochromes in the panel. Additionally, sample preparation and cell sorting procedures can impact the level of background noise. In cell sorting experiments, for instance, it is crucial to keep the threshold low to ensure that unwanted events are excluded, as they may interfere with downstream applications like PCR.

To characterize and minimize background noise, proper calibration and instrument standardization are essential. A well-defined scale calibration can improve data acquisition by aiding in cytometer setup, instrument comparison, and sample comparison. The introduction of precision light sources, such as quantiFlashTM, has enabled the characterization of a cytometer's PMT performance and the determination of its signal-to-noise ratio (SNR) and dynamic range (DNR). This allows for the selection of voltage/gain settings that correspond to the PMT's maximum efficiency and lowest electronic noise, optimizing experimental design.

Furthermore, the quantities Q and B are used to describe instrument sensitivity in relation to fluorescent particles. Q, the detection efficiency, accounts for factors such as laser power, optics, and target dye excitation efficiency. Low Q values may be due to issues like low laser power, fluctuations in flow speed, or low detector efficiency. By evaluating Q in conjunction with SNR and DNR, it becomes easier to compare instruments. The quantity B represents the background and is influenced by laser light, electronic noise, and autofluorescence of calibration beads.

shunzap

Photon current and voltage range

Photons are converted into electric current in a voltage-dependent manner in flow cytometry. Photomultiplier tubes (PMTs) are the most common detectors on commercial flow cytometers. Photons of light enter the PMT through a window and hit the photocathode. If the photon is of sufficient energy, it ejects an electron due to the photoelectric effect. This electron is then focused on one of several "fins" called dynodes, where the electrons are multiplied via secondary emission. The PMT amplifies the incoming signal in a linear, proportional manner. The output is an electronic signal pulse.

The PMT voltage is optimized to establish the optimum sensitivity of a flow cytometer for a given analytical experiment. The goal is to ensure that in every detector channel, the autofluorescence of unstained cells is clearly detected above the limit of sensitivity. The PMT voltage can be adjusted to increase or decrease detector sensitivity. The optimum PMT voltage can be determined using the "Peak 2" method, which involves running a dim fluorescent particle at different voltage settings and plotting the spread of the signal over the voltage series.

The amount of electronic noise in a flow cytometer needs to be measured since there is no predictable fixed value of dark current that can be read off the PMT's data sheet. Dark current consists of thermionic noise, leakage current inside the PMT, photon current by scintillation from glass, and field emission current, among others. The relative contributions of these sources to the dark current depend on the PMT voltage in a non-linear way. For example, between 200 V and 700 V, the PMT's dark current is dominated by leakage current, while between 700 V and 1,400 V, it is dominated by thermionic noise.

By characterizing the instrument's response over the entire PMT voltage range, the cytometer's signal-to-noise ratio (SNR) and dynamic range (DNR) can be determined. This allows for the selection of a voltage/gain corresponding to the PMT's maximum efficiency and, consequently, the lowest electronic noise. This can help with experiment design and improve data acquisition.

Frequently asked questions

Electrical noise in flow cytometry refers to the unwanted electrical signals that can interfere with the detection of fluorescent signals from cells.

Electrical noise occurs due to various factors such as thermionic noise, leakage current, photon current, and field emission current, which can be influenced by ambient electric fields or even cosmic rays.

Electrical noise can affect the sensitivity and resolution of flow cytometers. It can overlap with the signals from smaller particles, making them harder to detect and causing limitations in conducting, interpreting, and reproducing experiments.

Electrical noise can be minimised by optimising the PMT voltage to establish the optimum sensitivity of the flow cytometer. Well-defined scale calibration and the use of precision light sources, such as quantiFlashTM, can also help reduce electrical noise and improve data acquisition.

Common sources of electrical noise include electronic components, such as detectors with inherent sensitivity limits, and experimental conditions like Raman scatter and spillover from other fluorochromes.
