Electrical circuits are fundamental to powering and controlling electronic devices. Series and parallel circuits are the two fundamental ways in which to connect more than two circuit components. A series circuit is a type of electrical circuit in which the components are connected in a line, one after the other, so that the same current flows through all of them. In a series circuit, the current that flows through each of the components is the same, and the voltage across the circuit is the sum of the individual voltage drops across each component. A parallel circuit, on the other hand, is a type of electrical circuit in which the components are connected so that each component has its own separate branch and the same voltage is applied to each component. The total current in a parallel circuit is equal to the sum of the current in each of the individual branches.
| Characteristics | Series Circuit | Parallel Circuit |
|---|---|---|
| Current | The same amount of current flows through all components | The total current is the sum of the currents in each branch |
| Voltage | The voltage across the circuit is the sum of the individual voltage drops across each component | The same voltage is applied to all components |
| Components | Connected end-to-end in a line, forming a single path for current flow | Connected across each other, with each component having its own separate branch |
| Failure of One Device | Triggers the failure of other devices downstream | Does not affect other branches |
| Applications | Used to control power in offices | Used to power appliances in offices and homes |
Explore related products
What You'll Learn
- Series circuits have one path for current flow, with the same current through all components
- Parallel circuits have multiple paths for current flow, with the same voltage across all components
- Series circuits are current-coupled, meaning every device must function for the circuit to be complete
- Parallel circuits are more reliable for consumer electronics, as a single component failure does not compromise the entire circuit
- Series and parallel circuits are both used to power multiple devices, but they work in different ways
Series circuits have one path for current flow, with the same current through all components
A series circuit is a type of electrical circuit in which the components are connected in a single line, one after the other, forming a single path for the current to flow. This means that the same current flows through all the components in the circuit. Each component in a series circuit shares one electrical node with its nearest neighbour.
In a series circuit, if one component fails, the entire circuit is broken. For example, if one of the light bulbs in a string of Christmas tree lights burns out, the entire string becomes inoperable until the faulty bulb is replaced. Series circuits are sometimes referred to as current-coupled.
Series circuits were formerly used for lighting in electric multiple unit trains. For instance, if the supply voltage was 600 volts, there might be eight 70-volt bulbs in series (total 560 volts) plus a resistor to drop the remaining 40 volts. Series circuits for train lighting were superseded, first by motor-generators, then by solid-state devices.
Fuses and circuit breakers are examples of series circuits that control the operation of parallel circuits. A power strip is another example of series wiring.
