Electrical insulators are materials with a high resistivity that prevent the flow of electric current. They are used to coat wires and electrical equipment to prevent safety hazards and electric shocks. Insulators are poor conductors of electricity and have a high resistance to the flow of electric current. They are used in electrical appliances and equipment in homes, offices and streets. Insulators are made of materials such as plastic, rubber, glass, epoxy resins, fibreglass, mica, and porcelain.
| Characteristics | Values |
|---|---|
| Definition | Any substance that blocks or retards the flow of electrical or thermal currents |
| Other names | Dielectric (when placed in an external electric field, its internal positive and negative charges shift, creating an internal electric field that opposes the external one) |
| Use cases | Electrical appliances and equipment, motors, generators, transformers, cables, capacitors, alternators, on-board electronics, batteries, wires, plugs, etc. |
| Types | Solid (paper, nonwovens, films), liquid (resins, varnishes, mastics, oils), gaseous |
| Examples | Rubber, plastics, epoxy, phenolic plastics, glass, ceramic, silicon dioxide, mica, porcelain, polyethylene, crosslinked polyethylene, PVC, Kapton, asbestos, slate, marble, sulfur hexafluoride, Nomex, Formex, etc. |
| Resistivity | Greater than 10^8 Ω⋅m |
| Dielectric strength | Maximum value of the electric field that the material can withstand before an arc is triggered |
| Band gap | Large |
| Breakdown voltage | Voltage that gives electrons enough energy to be excited into the band above the "valence" band |
Explore related products
What You'll Learn
Electrical insulators are poor conductors
Electrical insulators are materials with a high resistivity, which is a property of the material. They form a barrier between the energised parts of an electric circuit and restrict the flow of current to wires or other desired conductive paths. Insulators are poor conductors of electricity because they have a high resistance to the flow of electric current. They are also referred to as nonconducting materials.
The efficacy of insulation materials is measured in terms of their thermal resistance, or R-value. The higher the R-value, the greater the thermal resistance of the material. Materials with larger resistivity values offer greater resistance to the flow of electric current and are therefore better insulators. For example, glass has a resistivity value of 1012 Ωm (ohmmeter), while copper has a value of 10-12 Ωm. Insulators are mainly used in applications where the prevention of the flow of electric charges is required.
Insulators are used in electrical appliances and equipment. They are also used to protect users of electrical devices from harmful shocks. For example, electrical wires are covered with insulation material to prevent safety hazards. Electrical plugs have an insulated covering to prevent electricity from flowing from the metal socket (conductor) to the user's body.
There are various types of materials used as electrical insulators, including solid and liquid forms. Solid insulators include paper, nonwovens, and films, while liquid insulators include resins. Flexible insulators are less than 1 millimeter thick and are sold as papers or fibres. Examples of flexible insulators include Nomex®, a meta-aramid with excellent thermal stability, and Formex®, a polypropylene in film or honeycomb panels. Rigid insulators include materials such as FR-4, a laminate made from epoxy resin and fibreglass, and Nokamex, a high-end laminate made of Kapton® polyimide and Nomex® aramid paper.
