When designing a printed circuit board (PCB), it is crucial to consider the minimum electrical clearance between components to ensure safety and functionality. This clearance, also known as creepage, is the shortest distance between conductor traces along the surface of the insulation material. It is distinct from clearance, which refers to the minimum distance through the air between conductors. The optimal distance depends on factors such as voltage level, signal frequency, pollution degree, insulation, and altitude. Industry standards like IPC-2221, IEC-6061, and IEC-62368 provide guidance on spacing to minimize hazards. With the trend towards miniaturization in PCB design, adhering to these standards while maintaining product size constraints becomes a challenge, especially when incorporating high-voltage circuits.
| Characteristics | Values |
|---|---|
| PCB trace clearance | 0.1 mm or 4 mils for general-purpose devices |
| PCB trace clearance | 0.13 mm or 5.1 mils for power conversion devices |
| Minimum spacing between wires | Not less than 4 mils |
| Minimum line distance | 10 mils |
| Pad diameter (mechanically drilled) | Minimum of 0.2 mm |
| Pad diameter (laser drilled) | Minimum of 4 mils |
| Aperture tolerance | 0.05 mm |
| Pad width | Minimum of 0.2 mm |
| Copper area safety distance | 20 mils |
| Copper area safety distance (whole board) | 10 mils |
| Clearance | The shortest path between two conductive parts measured through air |
| Creepage | The shortest path between two conductive parts measured along the surface of insulation |
| Creepage | Depends on CTI, pollution degree, working voltage, insulation, and altitude of the system |
