In electrical systems, the neutral is a grounded conductor that must be sized and treated differently from ungrounded phase conductors. When sizing the load for a 2-wire circuit, the grounded neutral conductor carries the same amount of current as the ungrounded phase conductor. Calculating the neutral size is crucial to ensure the safety of electrical equipment and machinery. This involves determining the maximum unbalanced load, which is the maximum net calculated load between the neutral conductor and any one ungrounded conductor. The neutral load calculation is especially important for 3-wire, 2-phase, or 5-wire, 2-phase systems, where the maximum unbalanced load is multiplied by 140%. Additionally, a demand factor of 70% is applied to neutral loads exceeding 200A for nonlinear loads. Properly calculating the neutral size ensures compliance with electrical codes and standards, such as the National Electrical Code (NEC).
| Characteristics | Values |
|---|---|
| Definition | In any electrical system, the neutral is a grounded conductor that you must size and treat differently from ungrounded phase conductors. |
| Sizing the neutral | You must size the neutral conductor to carry the maximum unbalanced current in the circuit (i.e., the largest load between the neutral and any one ungrounded phase conductor). |
| Calculating the first 200A of neutral current | 100% |
| Calculating resistive loads on the neutral exceeding 200A | 70% demand factor |
| Calculating inductive neutral current | 100% with no demand factor applied |
| Calculating the neutral current for a 3-wire, 2-phase or 5-wire, 2-phase system | Multiply the maximum unbalanced load by 140% |
| Calculating the neutral load for household electric ranges, wall-mounted ovens, counter-mounted cooking units, and electric dryers | Apply an additional demand factor of 70% to the amount in 220.61(B)(1) or a portion of 220.61(B)(2) |
| Calculating the neutral load for a feeder or service supplied from a 3-wire dc or single-phase ac system; or a 4-wire, 3-phase system; or a 3-wire, 2-phase system; or a 5-wire, 2-phase system | Apply an additional demand factor of 70% to the amount in 220.61(B)(1) or a portion of 220.61(B)(2) |
| Calculating the neutral load for a 5,500-watt clothes dryer | 3,850 volt-amperes |
| Calculating the neutral load for an office building | 216,000 volt-amperes |
| Calculating the neutral load for an industrial plant with a 400-ampere panel board supplied by a 208Y/120 volt, three-phase, 4-wire system | 67 amperes |
Explore related products
$21.98 $24.97
What You'll Learn
Calculating neutral size
In any electrical system, the neutral is a grounded conductor that must be sized and treated differently from ungrounded phase conductors. The neutral conductor is sized to carry the maximum unbalanced current in the circuit, or the largest load between the neutral and any one ungrounded phase conductor.
When sizing the load for a 2-wire circuit, the grounded neutral conductor carries the same amount of current as the ungrounded phase conductor. For 3-wire circuits, the grounded neutral conductor must carry the unbalanced load of the two ungrounded phase conductors. This type of installation has an unbalanced load unless both ungrounded conductors pull the same amount of current on each ungrounded phase conductor.
The first 200A of neutral current is calculated at 100%. For all resistive loads on the neutral exceeding 200A, a demand factor of 70% must be applied and then added to the first 200A calculated at 100%. Inductive neutral current is calculated at 100% with no demand factor applied.
For 3-wire, 2-phase, or 5-wire, 2-phase systems, the maximum unbalanced load is the maximum net calculated load between the neutral conductor and any one ungrounded conductor multiplied by 140%. When working with cooking equipment or a dryer load, the feeder neutral load is 70% of the demand load.
When calculating the neutral size for service conductors, it is important to note that 240V loads like dryers, stoves, and water heaters do not carry current on the neutral, except for a small amount for digital displays and control panels.
To calculate the neutral size, follow these steps:
- Determine the load on the neutral conductor by considering the number of current-carrying conductors and the manner in which they share loads.
- Calculate the first 200A of neutral current at 100%.
- For loads exceeding 200A, apply a demand factor of 70%.
- Add the value from step 3 to the 200A calculated in step 2.
- For inductive neutral current, calculate at 100% with no demand factor applied.
- If using a 3-wire, 2-phase, or 5-wire, 2-phase system, multiply the maximum net calculated load by 140%.
- If working with cooking equipment or a dryer load, apply a 70% demand load.
- Size the neutral conductor accordingly, ensuring it can handle the calculated load.
By following these steps, you can calculate the appropriate neutral size for your electrical system, ensuring it can safely handle the maximum unbalanced current in the circuit.
