In electronics, 'noise' refers to unwanted high-frequency disturbances or interference in a circuit. This noise can be caused by various factors, including electromagnetic interference, voltage fluctuations, current variations, and external environmental factors such as lightning discharges or electrical equipment. Noise can also be generated within the circuit itself due to thermal effects or signal processing techniques like dithering. The impact of noise can range from minor audio distortions to significant disruptions in sensitive electronic equipment. Understanding and mitigating noise in electrical circuits is crucial for maintaining the proper functioning and accuracy of electronic devices and systems.
| Characteristics | Values |
|---|---|
| Definition | Noise refers to variations in voltage or current that are often random, usually of relatively low amplitude, and always undesirable. |
| Types | Thermal noise, burst noise, flicker noise, shot noise, electrostatic noise, magnetic-coupled noise, inductive coupling, capacitive coupling, conducted noise, cosmic noise, solar noise, industrial noise, static noise, etc. |
| Causes | Resistance to the flow of electrons, lightning discharges, electrical disturbances in nature, solar storms, distant stars, industrial sources like automobiles, aircraft, ignition electric motors, etc. |
| Impact | Unwanted interference or disturbance in the circuit, voltage sags, transient waveforms, etc. |
| Solutions | Faraday cage, improved circuit layout and grounding, notch filters, twisted pair wiring, cooling of circuits, smaller resistors, filters to limit bandwidth, low-current biasing techniques, transient protection, etc. |
