An electrical board is a large rectangular box that contains electrical devices such as fuses, trip switches, and circuit breakers. The number of circuit breakers in an electrical board varies depending on the size of the home, with small homes having around 6 circuit breakers and larger homes having up to 20. Circuit breakers are protective devices that limit the amount of electrical current flowing in a circuit to prevent electrical fires, overloads, and short circuits. The main switch is another critical component of the electrical board, as it controls the flow of electricity in the home and can be used to turn off the electricity supply. GFCI or RCD switches are also important as they detect any missing electrical current in a circuit and trip when there is an imbalance, preventing electric shock and providing fire protection.
| Characteristics | Values |
|---|---|
| Definition | The electrical board is the beginning of the consumer's electrical installation. |
| Incoming supply | A large thick cable enters into a 'supply cut-out' and then goes to the electric meter. |
| Function | The electrical board divides the supply into various electrical circuits. |
| Appearance | A large, normally rectangular box. |
| Contents | Fuses, trip switches, and other components that enable the electrical system to function safely. |
| Consumer unit | A plastic or metal box containing switches with differing purposes. |
| Fuse box | A metal or plastic box containing fuses, fuse carriers, and switches. |
| Main Switch | A point of isolation for all electrical circuits within the electrical board. |
| Busbar | Rigid metalwork that connects the Main Switch to all circuits. |
| Circuit Breakers | Individual circuit protective devices that limit the amount of electrical current that can flow. |
| GFCI or RCD switches | Devices that detect any missing electrical current in a circuit and trip when there is an imbalance. |
| 3-phase electrical board | Accepts three incoming live supplies, used in large homes or commercial/industrial applications. |
| Number of circuit breakers | From 6 for small homes to 20 for larger homes. |
| Size | Can be several feet in height and width for commercial/industrial boards. |
| Circuit colours | Green (live), Red (tripped/overloaded), White (power off). |
| Wire colours | Black (hot), Red (secondary hot), White/Grey (neutral), Green/bare (grounding). |
| Replacement cost | $520 to $2,090 depending on type and complexity. |
Explore related products
What You'll Learn
- The electrical board is the beginning of a consumer's electrical installation
- Electrical boards contain devices such as fuses, trip switches and circuit breakers
- Circuit breakers protect your home by limiting the amount of electrical current in a circuit
- GFCI or RCD switches detect missing electrical current and trip when there is an imbalance
- The number of circuit breakers in an electrical board depends on the size of the home
The electrical board is the beginning of a consumer's electrical installation
An electrical board is the starting point of a consumer's electrical installation. The incoming mains supply is typically a large, thick cable that enters a 'supply cut-out' and then travels to the electric meter. After passing through the meter, the supply enters the electrical board, where it is distributed into various electrical circuits. The electrical board is usually a large, rectangular box that houses devices such as fuses, trip switches, and other components that ensure the electrical system functions safely. These devices also protect the cabling and electrical accessories within the system.
The electrical board contains critical components such as the Main Switch, which is the central point of control for the electricity supply to the entire home. It allows the supply to reach all the electrical circuits. The Busbar, a rigid metal component, connects the Main Switch to all the circuits. Circuit Breakers are another vital element; they are protective devices that limit the electrical current flowing in each circuit. They are designed to prevent electrical fires, overload, and short circuits from damaging cables and installations.
GFCI or RCD switches are additional safety features found in electrical boards. These devices detect any missing electrical current in a circuit and trip when there is an imbalance between the current flowing in the hot and neutral wires. RCDs, or Residual Current Devices, are particularly important as they protect against electrocution by quickly disconnecting power when a small 'leakage' is detected. This 'leakage' could be life-threatening if not addressed promptly.
The number of circuit breakers in an electrical board varies depending on the size of the premises. A small home might have six circuit breakers, while a larger home could have up to 20. Commercial and industrial electrical boards can be several feet in height and width, reflecting the scale of the installation and the number of circuits required.
It is essential to have the electrical board correctly designed and installed by a professional to ensure adequate protection for circuits, equipment, and personal safety. Regular maintenance checks are also crucial to identify any potential issues and ensure the system is functioning optimally and securely.
