Resistance in an electrical circuit is the property of a component or material to resist the flow of electric current. It is denoted by the symbol 'R' and measured in ohms (Ω). The greater the resistance, the smaller the current for a given voltage, and vice versa. Resistance is affected by factors such as temperature and the type of material used. For example, copper wire has low resistance, whereas rubber insulation has high resistance. Understanding resistance is crucial in circuit design as it influences the power consumption and behaviour of electronic components.
Explore related products
What You'll Learn
The relationship between voltage, current, and resistance
Ohm's Law can be expressed by the equation: voltage (V) = current (I) x resistance (R). This equation can be manipulated to solve for current and resistance. The first version of the formula, I = V/R, tells us that the electrical current in a circuit can be calculated by dividing the voltage by the resistance. In other words, the current is directly proportional to voltage and inversely proportional to resistance.
The second version of the formula tells us that if the current or resistance in a circuit is increased, the voltage will also have to increase, provided the other quantity remains constant. The third version of the formula tells us that we can calculate the resistance in a circuit if the voltage and current are known. If the current is held constant, an increase in voltage will result in an increase in resistance. Conversely, an increase in current while voltage is held constant will result in a decrease in resistance.
The power consumed by a device is determined by the voltage and current together. For example, a 1-ohm resistor will consume 1 watt of power when connected to 1 volt and 1 ampere. The power can be calculated using the equation P = VI = I^2R = V^2/R.
The amount of resistance a resistor has is determined by the relationship between the current through it and the voltage across it. Low resistance implies a good conductor, while high resistance implies a bad conductor. Materials such as copper, aluminium, and carbon have low resistance, while insulating materials such as glass, porcelain, or plastic have high resistance.
It is important to provide the correct voltage to a device as overheating can easily break things. For example, if a 1-volt device is given 2 volts, it will draw 2 amperes and generate twice the heat.
