The standard home main electrical line is the key element that funnels electricity into your home. Electrical lines can be overhead or underground. Overhead lines are attached to the side of your house and are known as service drops, while underground lines are referred to as service laterals. A standard service drop includes three cables or conductors: two insulated hot cables, each carrying 120 volts of electricity (240 volts across both wires), and a third bare wire that serves as the neutral conductor. The voltage and frequency of electric power differ between regions, with 230 volts and a frequency of 50 Hz being common in most parts of the world, while North America typically uses 120 volts and 60 Hz. Homes are connected to the electrical grid through a fuse box or circuit breaker, which provides overload protection to prevent overheating and fires.
Explore related products
What You'll Learn
Residential electrical service drops
A residential electrical service drop is the main connection between the power pole of the electric utility company and a house. It is a bundle of electrical cables that run from the power pole to the connection at the house. The service drop provides all the power to the house. If the service drop fails, all electricity in the residence will be shut down.
Service drops are attached to the side of a house and are quite common. They are also known as overhead service drops. However, they are vulnerable to catastrophic events, such as downed trees, large fallen limbs, or heavy ice buildup, which can take down a service drop. Fallen service drops are extremely dangerous as they carry enough electricity to power an entire house.
Service drops usually consist of three cables or conductors. Two of them are insulated hot cables, each carrying 120 volts of electricity (240 volts across the two wires). The third cable, usually a bare (uninsulated) aluminium wire with a steel core, serves as the neutral conductor and provides structural support for the entire service drop.
In recent years, housing construction has favoured underground service lines over overhead service drops. When the lines are underground, they are referred to as a service lateral. Buried lines are preferred because they are not vulnerable to falling trees, high winds, and other destructive effects of weather. They are also out of view and eliminate the danger of accidental contact with ladders or vehicles.
However, installing and repairing buried lines is much more costly and labour-intensive than with overhead service drops. Underground lines are also at risk of being struck by construction crews or even homeowners digging in their yards. They are also affected by shifting ground.
Solar Power: Big Savings, Small Bills
You may want to see also
Explore related products
Overhead vs underground lines
There are two methods of installing the power lines that carry electricity to your home: overhead and underground. Each method has its advantages and disadvantages.
Overhead Power Lines
Overhead power lines are a less expensive way to get power to your home. They are also less expensive to repair and upgrade. Overhead lines can be installed relatively quickly, as there is no need to dig trenches. They can also be built anywhere, and any voltage can be placed overhead. Overhead line construction starts with setting utility poles, which can be placed in nearly any type of terrain. Once the poles are in place, wires can be strung, and equipment like transformers, fuses, and reclosers can be installed.
However, overhead power lines are more susceptible to extreme weather conditions like high winds, freezing rain, lightning, wildfires, and ice storms. They are also vulnerable to damage from trees and vegetation, which requires regular trimming, and vehicle collisions.
Underground Power Lines
Underground power lines are protected from wind, wildfires, and tree branches and damage from most animals. They are also less susceptible to outages from vehicle collisions and have a reduced risk of electrocution from downed lines. They are aesthetically more pleasing, with poles and wires out of sight.
However, underground lines are more expensive to build and maintain. They require digging a trench deep enough to keep the lines away from surface activities like digging or construction. Underground lines are also more time-consuming and expensive to locate and repair in the event of a malfunction. They are vulnerable to earthquakes and flooding and are not practical in unstable sandy or rocky mountainous areas.
The decision between overhead and underground power lines depends on various factors, including cost, appearance, reliability, maintenance, and future upgrade needs. While underground lines offer better protection from the elements and improved safety, overhead lines are more cost-effective and easier to install and maintain.
How Costly Are Dimplex Electric Heaters to Operate?
You may want to see also
Explore related products
Service lateral vs service drop
A service drop is the bundle of electrical cables, or three individual wires, that run from the electric utility company's power pole to a connection at a house. The service drop provides a building with two 120 V lines of opposite phase, so 240 V can be obtained by connecting a load between the two 120 V conductors. In North America, the 120/240 V split-phase system is used for residential service drops.
The overhead power connection from the utility lines to the service entrance is referred to as the service drop. There are two types of overhead service drops: a mast service drop and a clevis service drop. An underground service connection is referred to as a service lateral. While overhead service drops were the standard for many years, more recent housing construction favours underground service lines.
Service lateral refers to the underground conductors between the service point and the first point of connection to the service-entrance conductors in a terminal box, meter, or other enclosures inside or outside the building wall. When the lines are underground, they are referred to as a service lateral rather than a service drop. Buried lines are preferred primarily because they are not vulnerable to falling trees, high winds, and other destructive effects of weather.
In North America, where single-phase distribution transformers for service drops are the norm, three-phase service drops are often constructed using three single-phase transformers wired in a Y configuration. This is called a transformer bank. Service conductors for a customer may be run underground, from a padmount transformer to a customer's meter.
Garage Door Opening: No Electricity Required
You may want to see also
Explore related products
Electrical service masts
The service mast is part of the house, but the conductors or wires passing through it belong to the power company. This distinction is important because it determines who is responsible for repairs when something goes wrong. In general, homeowners are responsible for maintaining and repairing their service masts, including any damage to the power meter box. The power company, on the other hand, is responsible for fixing issues with the electrical meter and the service lines, such as those damaged by storms or other events.
It is crucial to keep the area around the mast clear of vegetation and to avoid attaching anything to it. Homeowners should also periodically inspect the service mast for any signs of deterioration or damage, especially after severe storms, as falling trees and limbs can hit the mast, causing it to bend, crack, or detach from the home. If you suspect damage to your service mast, it is recommended to first turn off the home's electrical power at the main breaker for safety reasons. You should then contact a licensed professional electrician to ensure safe and code-compliant repairs.
It is worth noting that rules and regulations regarding electrical service masts can vary depending on your location. Therefore, it is always a good idea to check with your local electric utility company or a licensed electrician to understand your specific responsibilities and requirements.
Cleaning Electrical Contacts: Removing Verdigris Safely
You may want to see also
Explore related products
Circuit breakers and fuses
Every home is connected to the electrical grid through a fuse box or circuit breaker. Circuit breakers and fuses are essential safety devices that limit the amount of electricity flowing through electrical circuits to prevent fires, shocks, and damage. They detect short circuits between the line and neutral or ground wires, or when more current is being drawn than the wires can handle.
Circuit Breakers
Circuit breakers use a combination of thermal and magnetic elements to detect overloads and short circuits. They can be reset, making them more convenient and safer than fuses. They also reduce the risk of using incorrect amperage ratings, a common issue with interchangeable fuses. With proper maintenance, they can last for decades. When tripped, the breaker physically separates the contacts, stopping the flow of electricity.
Fuses
Fuses are simple devices that consist of a metal strip or wire that melts when too much current flows through it, breaking the circuit and stopping the flow of electricity. Fuses typically react faster to overloads and can be more sensitive to small overloads, offering more precise protection. However, they must be replaced after each use.
Regular Maintenance
Regular maintenance of circuit breakers and fuses is essential for ensuring the safety and reliability of a home's electrical system. Homeowners should regularly test, check for wear and listen for unusual sounds from their circuit breakers. While circuit breakers can last for many years, they don't last forever, and may need to be replaced after a certain number of years.
Electricians in Mt. Pleasant WI: Don's Electric LLC
You may want to see also
Frequently asked questions
A standard home main electrical line is the bundle of electrical cables that run from the electric utility company's power pole to the connection at your house. The cables descend from a higher spot to a lower spot, and all electricity to your home comes through this line.
A standard home main electrical line consists of three cables or conductors. Two are insulated hot cables, each carrying 120 volts of electricity (240 volts across the two wires). The third cable is usually a bare (uninsulated) aluminium wire with a steel core, which serves as the neutral conductor.
A service drop is an overhead electrical line, whereas a service lateral is an underground electrical line. Service laterals are becoming more common as they are not vulnerable to falling trees, high winds, and other weather effects.
A service mast is a roof-mounted, goose-necked conduit through which overhead electrical lines pass before they reach the meter and the panel. The service mast is part of the house, but the conductors passing through it belong to the power company.
