In electrical circuits, the letter 'L' is often used to represent an inductor or inductance. However, in AC power supplies, 'L' can also stand for Live or Line, indicating that the wire is carrying an electric current. This is distinct from Neutral (represented by 'N'), which is connected to the ground and typically has a voltage of 0V relative to the ground.
| Characteristics | Values |
|---|---|
| L in AC power supply | Live or Line |
| N in AC power supply | Neutral |
| L and N symbols | Used to apply for safety agency approval |
| Connection of terminal L | To the unearthed conductive part of the AC main supply |
| Connection of terminal N | To the earthed conductive part of the AC main supply |
| Connection of terminal FG | To the earth to protect from electric shock and noise interference |
| Interchangeability of neutral and line | Not interchangeable for safety reasons |
Explore related products
What You'll Learn
L can stand for 'Live' in AC power supply
In AC power supply, the symbol L stands for "Live" or "Line". This means that the wire carries the voltage relative to the ground. For example, in a 120vac power supply, the live wire carries 120 volts relative to the ground.
The live wire is also sometimes referred to as the "hot line". This is because it is the wire that carries the current and is capable of delivering an electric shock. For this reason, it is important that the live wire is never connected to the ground, as this could lead to electric shock and injury.
In a typical household AC power supply, the live wire is connected to the unearthed conductive part of the AC main supply. This is usually connected to the earthed conductive part of the AC main supply, which is the neutral wire. The neutral wire is connected to the ground and always has 0V compared to the ground.
It is important to note that the live and neutral wires are not interchangeable. The neutral wire is usually larger than the live wire, and it is also connected to the earth in the main breaker box. This helps to protect against electric shock and ensures that the power supply operates normally.
