The LM1117T is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current. It is a highly efficient and easy-to-use voltage regulator, making it a popular choice for electrical engineers and hobbyists. The LM1117T offers an adjustable output voltage range of 1.25 to 13.8 V through the use of external resistors, with fixed voltage output options also available. With its low power consumption, current limit, and thermal protection features, the LM1117T is particularly well-suited for battery-powered applications, SCSI bus active terminals, and portable computers.
Explore related products
What You'll Learn
The LM1117T is a low dropout voltage regulator
The LM1117T is available in an adjustable version, allowing users to set the output voltage from 1.25 to 13.8 volts with just two external resistors. It also offers a fixed 5-volt output option. This flexibility makes it suitable for a wide range of applications requiring stable and precise voltage regulation.
The LM1117T is widely used in modern electronic designs and is particularly trusted in industrial automation systems. Its precise voltage regulation ensures the reliability and accuracy of sensors and actuators in these environments. Additionally, the LM1117T is a popular choice for power supply units in merchant networks and servers, providing reliable and consistent power delivery.
The LM1117T is a Texas Instruments product and is part of a family of versatile low dropout (LDO) voltage regulators. These regulators are known for their stability and dependability, making them suitable for various applications. The LM1117T, in particular, is an excellent choice for devices that require a steady voltage supply, such as smartphones.
Overall, the LM1117T is a high-quality and easy-to-use voltage regulator that is well-suited for electrical engineers and hobbyists alike. Its low power consumption, fixed output voltage, and compatibility with battery-powered applications make it a versatile and dependable component for modern electronic systems.
