The third rail is the part of the subway track that is electric. It is located close to the ground and provides 600 volts of electricity to power subway cars and their ancillaries. The third rail is a safety hazard and can be deadly to anyone on the tracks. The risk can be mitigated through the use of platform screen doors, placing the conductor rail away from the platform, or covering the conductor rail. The third rail was first used in 1906 by Lionel electric trains, and is still used in many new systems, including the Copenhagen Metro, Taipei Metro, and Wuhan Metro.
| Characteristics | Values |
|---|---|
| Purpose | To provide electrical power to the power-train and ancillaries of the subway cars |
| Voltage | 600 volts DC |
| Risk | High risk of electric shock |
| Mitigation | Platform screen doors, placing the conductor rail away from the platform, covering the conductor rail |
| Conductor rail material | Special soft steel |
| Conductor rail length | 33 feet |
| Conductor rail weight | 100 pounds per yard |
| Return current | Usually flows through one or both running rails |
| Design | Third rail (current feed) and fourth rail (current return) |
| Contact shoe position | Below, above, or beside the third rail |
| Contact shoe type | Horizontal |
Explore related products
What You'll Learn
Third rail systems are a hazard to anyone on the tracks
Third rail systems are a means of providing electric traction power to trains. They use an additional rail, known as a "conductor rail", which is placed alongside or between the rails of a railway track. This rail is electrified and therefore poses a hazard to anyone on the tracks.
The dangers of third rail systems have been recognised for some time, with early attempts to mitigate the risk including the use of bottom or side contact rails, which allowed the conductor rail to be covered, protecting track workers from accidental contact. Despite these measures, third rail systems remain a hazard to anyone on the tracks, including both workers and passengers.
The electrified rail presents a risk of electric shock, and high voltages above 1500 V are not considered safe. As a result, very high currents are required to transfer adequate power to the train, leading to high resistive losses and the need for closely spaced feed points. This creates a dangerous environment for anyone in close proximity to the tracks, as accidental contact with the electrified rail can result in serious injury or death.
The risk of electric shock can be mitigated through the use of platform screen doors or by placing the conductor rail on the side of the track away from the platform. Additionally, the conductor rail can be covered with a coverboard, a plank supported by brackets, to prevent accidental contact. However, coverboards are not always feasible due to their impact on the structure and loading gauge.
The hazards of third rail systems have been highlighted in several incidents, including a 1992 case in Chicago where a person walked onto the tracks at a level crossing and suffered electric shock, resulting in a significant financial verdict against the transit authority. In another incident, the Valhalla train crash of 2015, it is believed that the third rail penetrated the interior of a passenger car, contributing to the deaths of five passengers. These incidents underscore the critical importance of effectively managing the risks associated with third rail systems to ensure the safety of individuals on or around railway tracks.
