When installing current-carrying conductors, electricians must be aware of the ambient temperature and the number of conductors installed together. The National Electrical Code (NEC) section 310-10 requires conductor derating in two situations: when the ambient temperature rises above 30 degrees Celsius, and when bundling more than three wires in a conduit or cable. Derating a conductor reduces the amount of current it can carry, protecting the wire's insulation from degradation by excessive heat. The size of the conduit does not matter for derating purposes. However, bundling too many conductors together can have the same destructive effect on a conductor's insulation as installing them in elevated temperatures. Therefore, it is crucial to consider derating conductors when facing such conditions to ensure the safe and efficient operation of electrical systems.
| Characteristics | Values |
|---|---|
| Number of current-carrying conductors in a raceway, cable, or covered ditch | More than three |
| Ambient temperature | Above 30°C |
| Conduit size | Does not matter |
| Insulation | Degradation due to excessive heat |
| Max circuit breaker size | 15, 20, and 30 amperes for 14, 12, and 10 gauge wire, respectively |
| Temperature correction and adjustment factors | Permitted to be applied to ampacity |
| Ampacity | Depends on wire gauge and type |
| Temperature rating | 90°C |
| Number of current-carrying conductors bundled in a cable or conduit | More than three |
| Individual grounded conductors | Counted as current-carrying conductors |
