The electrical system of the Toyota RAV4 is protected by multiple fuses, which are located in different fuse boxes throughout the vehicle. The location of the fuse boxes and the specific fuses they contain vary depending on the generation and model year of the RAV4. For example, the cigar lighter (power outlet) fuses for the Toyota RAV4 XA30 (2006-2012) are different from those in the XA40 (2013-2018) model. Additionally, there are discrepancies in information sources regarding the location of the fuse panels, with some placing them on the driver's side and others on the passenger side.
| Characteristics | Values |
|---|---|
| Fuse box location | Under the instrument panel (on the left side) |
| Cigar lighter (power outlet) fuses | #9 “P/OUTLET NO.1”, #18 “P/OUTLET NO.2”, #23 “CIG”, #24 “ACC”, #27 “PWR OUTLET”, #12 “ACC-B”, #18 “AC INV” (Power Outlet 115V) |
| Abbreviation meaning | FOG RR 7.5A - Power Source (Gasoline Model) |
Explore related products
What You'll Learn
Cigarette lighter fuse
The cigarette lighter fuse in a Toyota RAV4 is located in the fuse box under the steering wheel on the driver's side. There may be more than one cigarette lighter fuse, as different circuits are used for the cigarette lighter in different locations. For example, the one inside the armrest box and the cargo outlet are connected to one circuit (fuse #11), while the one near the HVAC is on another circuit (fuse #8).
To locate the correct fuse, look for a blue 15-amp fuse, as this is likely to be the power outlet fuse. The fuse box should have a cover that indicates what each fuse is for.
It's important to note that the wiring that connects the lighter socket to the vehicle's electrical system may be damaged, broken, or loose, interrupting the current flow to the lighter. Additionally, the problem could be with the device you're trying to use, such as a defective charger or adapter.
In some cases, the issue may not be a blown fuse at all. There could be an unplugged wire or cord in the trunk that needs to be plugged back in.
Regarding battery drain, the cigarette lighter fuse in older models may drain the battery when something is plugged in and the engine is off. However, newer versions do not seem to have this issue, as the cigarette lighter fuse turns off when the engine is off.
The Ultimate Guide to Safely Washing Electric Blankets
You may want to see also
Explore related products
Power outlet fuse
The 2009 Toyota RAV4 has multiple 12V power outlets fused at different amperages. Cigarette lighter and inverter outlets are typically 15 amps, while auxiliary outlets under the instrument panel are usually 7.5 amps. To avoid blowing fuses, devices like ham radios that draw around 8.5 amps should be plugged into 15-amp fused outlets.
RAV4 owners often face confusion about outlet fuse ratings and occasional blown fuses under heavy load. For example, a user on a Toyota RAV4 forum stated that they blew the fuse at their power outlet (cigarette lighter) and that their manual showed three fuse box locations. They checked the fuses in the two boxes under the hood but could not find the fuse in the third location, which was behind a panel to the left of the steering wheel. Another user replied that the fuse panel they were looking for was under the dash behind the hood release.
All three 12-volt outlets in the vehicle are powered by a 15-amp fuse, and the one 110-volt outlet is also controlled by a 15-amp fuse. The 7.5-amp ACC fuse does not power a socket but instead provides power to activate the relay for the outlets. This circuit does not draw much current, which is why a low-amp fuse is used.
For the 2013-2018 Toyota RAV4, the Cigar Lighter (power outlet) fuses are #9 "P/OUTLET NO.1" and #18 "P/OUTLET NO.2" in the Instrument Panel fuse box. The fuse box is located under the instrument panel on the left side.
Testing Electric Fan Amp Draw: DIY Guide
You may want to see also
Explore related products
Fuse box location
The location of the fuse box in a Toyota RAV4 depends on the model and year of manufacture.
For the Toyota RAV4 XA40 model, produced between 2013 and 2018, the fuse box is located under the instrument panel on the left side. For left-hand-drive vehicles, simply open the lid to access the fuses. The cigar lighter fuses in this model are #9 "P/OUTLET NO.1" and #18 "P/OUTLET NO.2".
The 5th generation Toyota RAV4, produced from 2019 onwards, has a fuse box located on the left side under the dashboard. It is covered by a protective cover. The P/OUTLET fuse is for the cigarette lighter, and in the upper part of the box are fuses for the electric glass lifters and electric drive of the seats.
For the Toyota RAV4 hybrid models, the fuse box is found on the right side, where the battery is located in the right-hand side of the luggage compartment behind a protective cover.
Electrical Stimulation and MS: Is It Safe?
You may want to see also
Explore related products
Abbreviation meanings
Abbreviations and their meanings for the Toyota RAV4:
FOG RR: This abbreviation has conflicting interpretations. Some sources indicate it stands for fog lights, while others suggest it pertains to the rear window defogger.
P/OUTLET: This fuse is responsible for the operation of the cigarette lighter.
ST: This abbreviation stands for Starter Relay and is associated with the RHD (right-hand drive) configuration.
XA30W/CA30W: These designations refer to the Toyota RAV4's third generation, produced from 2006 to 2012.
XA40: This abbreviation pertains to the fourth generation of the Toyota RAV4.
CA50W/XA50W: These designations refer to the Toyota RAV4's fifth generation, produced from 2019 onwards.
It is important to note that the location and purpose of fuses, relays, and electronic controls may vary based on factors such as the year of manufacture, equipment level, and region of supply. Always refer to reliable sources and specific generation details for accurate information regarding the electrical system of your Toyota RAV4.
Relocating Electrical: Is It Worth the Effort?
You may want to see also
Explore related products
Seat heater fuse
A fuse is an essential safety feature in a car's electrical system, including the seat heater system. It acts as a safeguard, breaking the electrical circuit when the current exceeds a safe level, thereby protecting the system from damage.
In the context of the RAV4, specifically the 2012 model, there are some variations in the fuse panel configuration. While some RAV4 models have a fuse panel under the dash, others have two constant 12V fuse positions. For those seeking to install a DIY seat heater, understanding the power source and fuse requirements is crucial.
The Toyota RAV4 forums offer insights into the fuse requirements for heated seats. One source mentions a fuse position labelled S-HTR in the fuse panel, requiring a 15 Amp fuse. Another forum post mentions the S/HTR fuse, indicating it is located in the engine bay. Additionally, a 2019 RAV4 owner seeks information about the location of the SeatHeater fuse under the dash.
It is important to note that installing seat heaters may involve tapping into the fuse box, and ensuring the correct fuse rating is critical. A fuse with too low a rating will blow frequently, while a rating that is too high may not blow when necessary, risking damage to the system.
Transform Billboards: Electrifying Your DarkRP Experience
You may want to see also
Frequently asked questions
The fuse box is located under the instrument panel on the left side. For left-hand drive vehicles, simply open the lid. For right-hand drive vehicles, the fuse box is behind a cover.
The cigarette lighter fuses are #23 “CIG”, #24 “ACC”, #27 “PWR OUTLET”, and #12 “ACC-B” in the Instrument panel fuse box.
The power outlet fuses are #9 “P/OUTLET NO.1” and #18 “P/OUTLET NO.2” in the Instrument panel fuse box.
Yes, there are three fuse boxes in the Toyota RAV4. Two are located under the hood, and one is located in the interior.
You can find a diagram of the fuse panels on the Toyota TIS information system website, which you can subscribe to for $25 for 2 days of access.
