An electrical system is an essential component of most aircraft, powering a variety of instruments and equipment. The capacity and complexity of electrical systems vary across aircraft, from light, piston-powered, single-engine planes to modern, multi-engine jets. Electrical systems are typically powered by generators or alternators, which may be engine-driven or powered by an APU, hydraulic motor, or Ram Air Turbine (RAT). These systems provide power to instruments such as the airspeed indicator, altimeter, compass, attitude indicator, heading indicator, and turn coordinator, all of which are crucial for safe flight operations and help pilots maintain control and make informed decisions.
| Characteristics | Values |
|---|---|
| Purpose of electrically-powered instruments | Provide pilots with data about the flight situation of the aircraft, such as altitude, airspeed, vertical speed, heading, etc. |
| Instrument examples | Gyroscopic instruments, including attitude indicators, heading indicators, and turn coordinators; airspeed indicators; altimeters; compasses |
| Power source | Engine-driven generators or alternators; APU; hydraulic motor; Ram Air Turbine (RAT) |
| Voltage | 115-120V/400HZ AC, 28V DC or 14V DC |
| Backup power | Static inverter to power essential AC bus from aircraft batteries in case of loss of all AC power generation |
Explore related products
$26.72
$71.74 $91.99
What You'll Learn
Gyroscopic instruments
The attitude indicator, also known as the artificial horizon, is a critical gyroscopic instrument. It displays the aircraft's attitude or relation to the horizon. The aircraft symbol appears to fly around the fixed axis of the artificial horizon gyroscope, providing pilots with information about the aircraft's pitch and roll. This instrument is particularly useful in conditions of poor visibility, allowing pilots to maintain level flight and make turns without visual references outside the cockpit.
The heading indicator, or directional gyro, is another essential gyroscopic instrument. It displays the aircraft's heading in compass points relative to magnetic north. The gyro axis is initially aligned with the horizon, but due to precession caused by the Earth's rotation, it requires regular calibration throughout the flight, especially when flying towards the poles.
The turn coordinator is a unique gyroscopic instrument that provides dynamic axis alignment. It displays the rate of turn and slip, indicating whether the aircraft is turning or banking. Unlike the artificial horizon, the turn coordinator's axis alignment is short-term and responsive to the aircraft's movements.
In summary, gyroscopic instruments play a vital role in aviation by providing pilots with essential information about the aircraft's attitude, heading, and turn coordination. These instruments are typically powered electrically or pneumatically and include the attitude indicator, heading indicator, and turn coordinator. Each instrument utilizes the stability of a spinning rotor to provide accurate data, enhancing the pilot's situational awareness and decision-making capabilities during flight.
