What You'll Learn
- Some aircraft instruments are electrically powered, like the heading and attitude indicators
- Pneumatic systems, or vacuum/pressure systems, power the autopilot and de-ice systems
- Vacuum systems are simple but quirky, with a reputation for failure
- Modern pumps use aluminum and composite materials, improving reliability
- Pneumatic system failures are rare but almost always fatal
Some aircraft instruments are electrically powered, like the heading and attitude indicators
Aircraft instruments like the heading and attitude indicators are electrically powered in some aircraft. The heading indicator is an instrument used by the pilot to determine the aircraft's heading and navigate. Attitude indicators, also known as artificial horizons or gyro horizons, show the aircraft's orientation relative to the Earth's horizon.
In most aircraft, the heading and attitude indicators are pneumatically powered, but in some newer aircraft, they are electrically powered. Pneumatic systems, also known as vacuum or pressure systems, are critical to the safety of the flight, especially during night flights or flights in instrument meteorological conditions (IMC). While accidents due to pneumatic system failures are rare, they are almost always fatal.
There are several types of attitude indicators, including traditional, electric, digital, and all-in-one indicators. The electric attitude indicator was first allowed by the Federal Aviation Administration in 2003 as a backup to the gyro systems in non-commercial aircraft under 12,500 pounds. In 2015, the FAA further allowed aircraft under 6,000 pounds to use electronic indicators as their primary instrument.
Digital attitude indicators, which use solid-state electronics, do not have pitch and bank restrictions and are equipped with battery backup power. They are lighter, require less maintenance, and improve the overall flying experience. The electric attitude indicator provides a quick snapshot of the aircraft's pitch and bank attitudes, with the miniature aircraft on the gauge mirroring the aircraft's movements.
Electric Force Lines: Myth or Reality?
You may want to see also
Explore related products
Pneumatic systems, or vacuum/pressure systems, power the autopilot and de-ice systems
Pneumatic systems, also known as vacuum or pressure systems, are critical to the safety of an aircraft during flight, especially when flying at night or in instrument meteorological conditions (IMC). These systems power the autopilot and de-icing systems, as well as the heading and attitude indicators in most general aviation (GA) aircraft.
At the heart of pneumatic systems is a pressure or vacuum-creating engine-driven air pump. There are two main types of air pumps: wet and dry. Wet air pumps lubricate the inside of the pump using engine oil, while dry air pumps, which are more common, have self-lubricating graphite vanes inside the casing. In both types of pumps, air is drawn into the system through a filter, creating a fast-moving stream of air that passes over the vanes within the heading and attitude indicator gyros, causing them to rotate at approximately 10,000 rpm.
The attitude indicator, also known as an artificial horizon, shows the aircraft's relation to the horizon. This information is crucial for the pilot to determine if the wings are level and if the aircraft nose is pointing above or below the horizon. The attitude indicator is especially useful during instrument flight and in conditions of poor visibility. In many advanced aircraft, the attitude indicator is replaced by a Horizontal Situation Indicator (HSI), which combines the magnetic compass with navigation signals and a glide slope.
The de-icing function of pneumatic systems is typically found on smaller turboprop aircraft and older aircraft. Pneumatic de-icing boots, made of layers of rubber or elastomers, are placed on the leading edge of an aircraft's wings and stabilizers. These boots have one or more air chambers that are rapidly inflated and deflated to break the adhesive force between ice and the rubber, allowing the ice to be carried away by the airflow. This system is known as a weeping wing, running wet, or evaporative system.
While failures in pneumatic systems are rare, they can have fatal consequences. Redundancy in pneumatic systems is important to mitigate the risks of system failure. Newer aircraft often come with redundant systems, while older aircraft may require the installation of redundancy measures such as electrically-powered backup attitude and heading indicators, air pump redundancy, or a standby vacuum system.
