Electrical transformers use oil, often mineral oil, for several reasons. The oil acts as a coolant, drawing heat away from the transformer's core and coils and conducting it outside, where it can be dissipated into the air. It also has excellent electrical insulating properties, suppressing corona discharge and arcing. Additionally, the oil protects the solid insulation (paper) inside the transformer. Oil-filled transformers are common in high-power applications, especially in mains distribution networks. However, they are not suitable for all environments due to the risk of fire and spills. As a result, alternative fluids with higher flashpoints and less flammability, such as natural and synthetic esters, are becoming more popular.
| Characteristics | Values |
|---|---|
| Purpose | Insulation and cooling |
| Composition | Petroleum base oil and additives like anti-oxidants and metal deactivators |
| Types | Mineral oil, vegetable-based oils, natural esters, silicone or fluorocarbon-based oils, transformer oil |
| Functions | Insulate, suppress corona discharge and arcing, serve as a coolant |
| Properties | High dielectric strength, thermal conductivity, chemical stability, flash point >140 °C, pour point <-40 °C, dielectric breakdown >28 kVRMS |
| Testing | Furan testing every 2 years, DGA testing, ASTM International, International Standard, British Standards |
| Maintenance | Replacing old oil, adding new oil, cleaning the transformer oil tank |
Explore related products
What You'll Learn
Oil is a good insulator and prevents arcing
Oil is a key component of electrical transformers. It is used as an insulator and a coolant, with the ability to absorb and transmit heat, preventing transformers from overheating and suffering damage.
The insulation function of transformer oil is critical to preventing current from crossing a predetermined path. The oil fills the air gaps, improving the quality of the paper insulation. The oil's high dielectric strength ensures that it maintains its integrity when exposed to a strong electric field, preventing arcing and short circuits.
The type of oil used in transformers varies, with mineral oil being the most common. Mineral oil has a fire point of around 165 degrees Celsius, which does not qualify it as a suitable fluid for applications requiring less flammable options. Natural esters, with a higher flashpoint, are now often used in such cases. Vegetable-based oils, such as FR3® fluid, are also used due to their biodegradability, higher flashpoints, and ability to increase the lifespan of the transformer's insulation system.
The quality and condition of the oil are crucial to the smooth operation of the transformer. Regular testing and maintenance are required to ensure optimal performance and longevity. High acidity, for example, can decrease insulation performance and increase the risk of short circuits.
