There are several electrical splice connector kits available on the market that are approved for use in rewiring existing buildings where the cable is concealed. Tyco, for example, manufactures NM splices that are concealable and acceptable under the National Electrical Code (NEC) for rewiring in existing buildings. These types of push-together connectors are legal to use according to the NEC, although some professionals have expressed concerns about their safety. It is important to note that proper splicing techniques, such as soldering and shrink-wrapping, are crucial for ensuring the safety of electrical connections.
| Characteristics | Values |
|---|---|
| Approved concealable electrical splice connectors | Tyco, NSi Industries, SpliSeal, Wagobox, TE Connectivity |
| Applicable laws | National Electrical Code, Articles 545, 550, 551 |
| Applicable scenarios | Exposed cable wiring, rewiring/repairing in existing buildings with concealed cables |
| Cable types | Nonmetallic-Sheathed Cable, NM-B cable |
| Safety considerations | Proper splicing techniques, accessible wires and junctions, colour-coding compliance |
Explore related products
What You'll Learn
- Tyco makes concealable NM splices approved by the NEC
- Concealable splices are only permitted for non-permanent cable connections
- Dummy-proof splice devices are required to be approved for concealment
- Splice kits for in-wall use exist but are not widely available
- Splicing can be done safely with soldering, shrink wrap, and twist-on caps
Tyco makes concealable NM splices approved by the NEC
Tyco Electronics manufactures in-wall/boxless NM splices that are approved by the National Electrical Code (NEC). These splices can be used without a junction box (J-box), and are legal under the 2014 NEC. They are designed for use with Romex cable, which is the only brand of NM cable available in many hardware stores.
While Tyco's NM splices are approved by the NEC, they have received mixed reviews from electrical professionals. Some users have found them convenient and effective, while others have encountered challenges with the assembly process due to small or unclear instructions. It is important to note that these splices are intended for repair and not as a substitute for a proper J-box.
Tyco's NM splices offer a creative solution for specific electrical applications. However, some professionals still prefer traditional methods, such as using a junction box with appropriate cable connectors and wire nuts for splicing. It is worth noting that Tyco may have improved the product since its initial release, addressing some of the concerns raised by early adopters.
The Tyco NM splices provide an alternative for situations where accessing a junction box is challenging or where traditional splicing methods are impractical. While they may not be the preferred choice for all electricians, they can be a useful option in certain scenarios, especially with the necessary precautions and proper understanding of electrical safety guidelines.
Understanding Electrical Diagrams: Right-to-Left Reading Explained
You may want to see also
Explore related products
Concealable splices are only permitted for non-permanent cable connections
In electrical engineering, splicing is a common practice, and when performed correctly, it is perfectly safe. Splicing can be done in a variety of ways, including soldering, shrink wrapping, and twist-on caps with proper strain relief. However, it is important to note that incorrect splicing can lead to potential issues, and as a result, certain types of splicing are not permitted in certain situations.
Concealable splices, for instance, are subject to specific regulations. According to the National Electrical Code (NEC), concealable splices are only permitted for non-permanent cable connections. This means that if a cable is concealed, it cannot be permanently attached to structural members. Specifically, the NEC states that “all electrical junctions must be accessible”, therefore, junctions cannot be hidden behind walls.
This restriction is in place to ensure that splices are easily accessible for inspection, maintenance, and repair. By having the wires inside a box, they remain accessible and can be inspected or worked on without the need for breaking into walls or other concealed areas. This not only ensures safety but also facilitates easier maintenance and troubleshooting.
While there are in-wall splice kits available, such as the Tyco Electronics Romex Splice Kit, their use is limited to specific situations. These kits are designed for Nonmetallic-Sheathed Cable (NM) and meet the requirements of 334.40(B), which pertains to specific wiring regulations. However, it is important to note that these kits are typically used for retrofitting existing NM cables and are not approved for J-boxless cable extensions.
Stylish Electric Baseboard Heaters: Warmth with a Design Edge
You may want to see also
Explore related products
Dummy-proof splice devices are required to be approved for concealment
One example of a dummy-proof splice device that is approved for concealment is the NM Cable Splice Kit. These kits are specifically designed for Non-Metallic (NM) cables and provide a fast and reliable way to splice or tap 2-wire and 3-wire NM cables with a ground, up to 300 volts. The manufacturers of these kits claim that they are approved for use in rewiring projects within existing structures, referring to the relevant NEC articles.
It is important to note that the NEC has updated its requirements over the years. For example, the 2014 NEC code cycle introduced more precise language, requiring these devices to be listed (such as UL) and deemed non-metallic sheathed cable interconnector devices. Additionally, the 2014 code cycle removed permission for using the device as part of "rewiring," replacing it with "repair wiring" only.
To ensure compliance with the latest standards, it is crucial to refer to the most current electrical codes, such as the 2020 Code cycle of the NEC. By following these approved methods and using approved products, individuals can safely and effectively utilize dummy-proof splice devices for concealed electrical connections.
Are Electric Blankets Safe for Canine Comfort?
You may want to see also
Explore related products
Splice kits for in-wall use exist but are not widely available
There are also electrical professionals who have expressed concerns about the legality of certain splice kits for in-wall use. In particular, they highlight the importance of ensuring that any wiring and splices are accessible, even if they are not installed inside a box. This accessibility requirement is crucial for potential replacement or maintenance.
Additionally, it's worth noting that some splice kits may be more suitable for specific types of wiring. For example, the aforementioned Tyco Electronics Romex Splice Kit is intended for use with NM cable, which follows specific colour codes for its wires. However, in one instance, the colours of the wires in the kit were questioned, raising concerns about their compliance with standard US colour codes.
While splice kits for in-wall use are available, they may require careful consideration to ensure they meet the necessary safety and accessibility standards. It is always advisable to consult with qualified electrical professionals or seek advice from reliable sources to ensure that any electrical work complies with local regulations and is performed safely.
Electric Eels: Who Are Their Predators?
You may want to see also
Explore related products
![221-2401 | WAGO Lever-Nuts® Inline Splicing Connector | for Solid and Stranded Conductors | 2-Conductor with Operating levers | 24-12 AWG | Transparent housing | White Cover | [Box of 60 Pieces]](https://m.media-amazon.com/images/I/61yTGs92OcL._AC_UY218_.jpg)
Splicing can be done safely with soldering, shrink wrap, and twist-on caps
Splicing can be done safely with the use of soldering, shrink wrap, and twist-on caps. These methods can be used to connect and insulate wires in electrical installations.
Soldering is a widely used procedure in electronic assemblies, involving joining two stranded wires in a straight line. To solder wires, you will need a soldering iron, solder filler wire, stranded copper wire, and a wire stripping/snipping tool. It is important to exercise caution when soldering to avoid burns and electrical shock. Protective gear such as gloves and eyewear should be worn, and the work should be done in a well-ventilated area to avoid inhaling harmful vapors. After soldering, the splice can be insulated with heat shrink tubing or electrical tape.
Heat shrink tubing is a type of insulation that can be used to protect and insulate electrical wires and connections. It is a flexible, plastic tubing that shrinks in size when heated, providing a tight fit around the wires. Heat shrink tubing can be cut lengthwise and reattached using a clean, steep angle cut and heating the tubing evenly. Self-annealing tape, a type of self-fusing tape, can also be used to seal the cut edges.
Twist-on caps, or twist splice wire connectors, are another type of splicing method that provides an inexpensive and insulated way to terminate wires. They are designed to meet industry standards and are color-coded for easy identification. The connectors feature a square-wire spring thread that provides a tight and secure connection. Twist-on caps are tool-less, making them easy to install and perfect for electrical installations.
By using soldering, shrink wrap, and twist-on caps, splicing can be done safely and effectively, ensuring reliable and secure connections for electrical installations.
Grounding Your Home: Electrical Safety Basics
You may want to see also
Frequently asked questions
Yes, Tyco and similar types of push-together connectors are approved to be used according to the National Electrical Code (NEC). They are legal to be covered in a wall when retrofitting an existing NM cable.
A proper splice is perfectly safe and can be accomplished through soldering and shrink-wrapping, the correct use of twist-on caps with proper strain relief, or a variety of other splicing techniques.
Tyco Electronics offers a Romex Splice Kit that meets the requirements of 334.40(B) without needing a junction box. Another example is the NSi Industries Non-Metallic Cable Splice for a 2-Conductor Cable with Ground NMS-2.
Some tools and supplies for wire splicing include wire strippers, heat shrink, wire crimpers, cable cutters, and other electrical supplies.
