RV owners may want to convert their propane furnace to an electric one to avoid the high costs of propane and the inconveniences of refilling their tanks. While it may be possible to convert an RV propane furnace to electric, it is important to consider the potential challenges and limitations. For instance, the electric conversion may require a higher power draw, which could lead to constantly tripping the circuit breaker. This means that other appliances and devices may need to be turned off while the furnace is running in electric mode. To address this issue, RV Comfort Systems offers a hybrid heating solution called CheapHeat, which allows users to switch between gas and electric heat sources. The CheapHeat system is designed to work with the existing propane furnace, providing an affordable, efficient, and versatile heating option for RVs.
| Characteristics | Values |
|---|---|
| System | RV Comfort Systems CheapHeat Add-On System |
| Heating source | Electricity |
| Heating element | Tungsten heating coils |
| Power source | AC power from shore connection or generator |
| Voltage | 120V or 240V |
| Power consumption | Less electricity than a furnace fan |
| Safety | Safeguarded against failure by redundant methods; no carbon monoxide produced |
| Ease of installation | Can be installed alongside existing propane furnace or electric heating system; integrates smoothly with existing ductwork and thermostats |
| Cost | $249 to $695 |
| Dual-fuel capability | Can switch between gas and electric modes |
| Energy efficiency | Reduces propane consumption and operating costs |
| Other benefits | Eliminates cold air blowing during pre-cycling and post-cycle cool down; blower motor likely to last longer |
Explore related products
What You'll Learn
The benefits of using the CheapHeat system
The CheapHeat system offers a range of benefits for RV owners looking to convert their propane furnace to electric. Firstly, it provides versatility and flexibility in heating options. The system can be installed alongside an existing propane furnace or electric heating system, allowing users to choose between propane, electricity, or a combination of both. This flexibility means that users can select the most cost-effective and efficient heating source depending on their situation, such as taking advantage of nightly or weekly RV park stays where power is included in the rate.
Another advantage of the CheapHeat system is its ability to address the limitations of standard electric or gas furnaces in RVs, such as high fuel consumption, uneven heating, or inadequate insulation. By adding an electric option, the CheapHeat system helps reduce propane consumption, lower operating costs, and improve energy efficiency. The system's electric mode eliminates the energy loss associated with propane furnaces, resulting in a true one-to-one BTU per hour heat output.
The CheapHeat system also stands out for its ease of installation and integration. It can be installed in most RVs and smoothly integrates with existing ductwork and thermostats, minimizing the need for extensive modifications. The system includes a solid-state controller that communicates directly with the existing wall thermostat and fan motor, allowing users to conveniently select their preferred heating mode. Additionally, the system offers three wattage ratings (1,800, 3,750, and 5,000 watts) to accommodate different shoreline power limitations.
Safety is another key benefit of the CheapHeat system. It includes redundant integral safety measures, such as a bi-metal high-limit safety switch and a fusible link safety device, to protect against over-temperature and over-current situations. The absence of carbon monoxide production when using electric heat further enhances the system's safety profile. With its comprehensive safety features, the CheapHeat system provides peace of mind for RV owners.
Fossil Fuels: Powering Our World with Electricity
You may want to see also
Explore related products
How to install the CheapHeat system
The CheapHeat system is an add-on module that enables you to run your furnace like a large space heater, using AC power from shore or generator connections to heat your RV instead of propane. This system is designed to address the limitations of standard electric or gas furnaces in RVs, such as high fuel consumption, uneven heating, or inadequate insulation. It provides an affordable, efficient, and versatile heating solution.
To install the CheapHeat system, follow these steps:
Firstly, ensure you have the correct model for your RV. There are three models available, so you can choose the one that best fits your furnace and usage needs. The system requires a 50-amp service, so make sure your RV park can accommodate this.
Next, the unit is mounted directly downstream of the existing gas furnace. The CheapHeat system employs tungsten heating coils powered by 120 or 240-volt AC to generate heat. A 12-volt fan motor on the furnace pushes the heated air through the ducts in the RV. The fan motor only operates when heat is being produced in electric mode, which is a key difference from gas furnaces.
The CheapHeat system also includes a solid-state controller that communicates with the existing wall thermostat and the fan motor. This allows you to easily select between "Electric" or "Gas" on a wall switch, depending on your preferred energy source.
Finally, you can enjoy the benefits of your new heating system! The CheapHeat system is deemed safe, as it has redundant integral safety measures, and no carbon monoxide is produced when using electric heat. It is also energy-efficient, reducing propane consumption and extending your fuel reserves. With the CheapHeat system, you can stay warm and comfortable wherever your RV adventures take you.
The Intriguing Link Between Gravity, Electricity, and Magnetism
You may want to see also
Explore related products
How to choose between propane and electric heat
When it comes to choosing between propane and electric heat for your RV, there are several factors to consider, including cost, convenience, and efficiency. Here are some key points to help you make an informed decision:
Cost
The cost of propane vs. electricity is an essential consideration for many RV owners. Propane is generally considered the cheaper option, especially if it costs less than $3.14 to $4.47 per gallon. However, electricity can also be cost-effective, depending on your usage and the regulations of your RV site. Some campsites include electricity in their fees, making electric heating a more economical choice in those cases.
Convenience
If you frequently camp off-grid or engage in boondocking (camping without hookups), propane heaters may be more convenient since they don't rely on electricity. Electric heaters require a reliable power source, and while generators can be used, running them all night is not recommended. Therefore, if you prioritize flexibility and independence in your RV adventures, propane might be the preferred option.
Efficiency
Electric heaters are often more efficient than propane heaters. Most electric heaters are 100% efficient, while RV propane furnaces typically operate at 70-75% efficiency or even lower. This means that with propane, more energy is lost as heat escapes, resulting in higher costs to maintain the same level of warmth.
Safety and Ventilation
Propane heaters require proper ventilation to reduce the risk of carbon monoxide poisoning. Electric heaters, on the other hand, are clean-burning and do not produce harmful emissions, making them a safer choice from a ventilation perspective.
Temperature Considerations
The temperature range you expect to encounter during your RV trips is another factor to consider. Propane heaters tend to add moisture to the air, which can be beneficial in drier climates or seasons. Electric heaters, in contrast, provide dry heat, which may be preferable in humid conditions.
Camping Frequency and Duration
How often and for how long you camp in cold weather also plays a role in your decision. If you only occasionally camp in cold weather, sticking with your built-in RV propane heater or a simple upgrade like a ceramic space heater may be the most sensible and cost-effective choice.
In summary, both propane and electric heating options have their advantages and disadvantages. By carefully considering your camping habits, budget, and personal preferences, you can make an informed decision about which heating method will best suit your RV lifestyle.
Lessons From 1993: Avoid the Electric Fence!
You may want to see also
Explore related products
The cost of converting to an electric furnace
The cost of converting an RV propane furnace to electric depends on the system and the complexity of the installation. Some people opt for a conversion kit, such as the CheapHeat Add-On System, which can be installed alongside an existing propane furnace or electric heating system. This system provides versatility, allowing users to choose between propane or electricity for heating. The manufacturer claims that the system is affordable, efficient, and safer than using portable space heaters. The cost of the CheapHeat system is not immediately clear, but one user on a forum estimated that the unit would cost around $1000 including tax, shipping, and extras, and even more if professional installation is required.
Another user on a forum mentions that they purchased a Honeywell HHF360V portable heater rated at 1500 watts for around $30, which helped reduce their electricity usage compared to a furnace. This option is significantly cheaper than the previous one but may not be as powerful for heating an RV in colder climates.
It is important to note that converting an RV propane furnace to electric may require managing power usage to avoid tripping the circuit breaker. This may involve running certain appliances, such as the refrigerator and water heater, on propane while the furnace is running on electric.
Additionally, there may be costs associated with modifying the ductwork, adding breakers, and purchasing the necessary materials, such as wires and heat strips. These costs can add up, especially for older RVs that may require more extensive modifications.
Overall, while there are cost-effective options available, such as the CheapHeat system, the final expense of converting an RV propane furnace to electric will depend on the specific circumstances and requirements of the RV owner.
Understanding the Intrinsic Link Between Electricity, Magnetism, and Light
You may want to see also
Explore related products
The safety features of the CheapHeat system
The CheapHeat system offers several safety features for RV owners. Firstly, it eliminates the need for a portable heater, reducing the risk of fire or overheating a wall socket. It also removes the possibility of a furnace misfiring and causing a gas explosion, as well as potential manufacturer errors during installation that could lead to the flue pipe burning the outer wall of the RV.
The CheapHeat system is designed with durability and reliability in mind, exceeding industry standards. It is UL certified and RVIA compliant in both the United States and Canada, ensuring its safety and authenticity. The system also features a bi-metal high-limit safety switch wired into the coil assembly, protecting it from over-temperature situations. This is further enhanced by a failsafe device called a fusible link, which acts as an in-line circuit breaker, providing protection against over-current and overheating issues.
The CheapHeat system's redundant integral safety measures and absence of carbon monoxide production make it a safe and viable option for RV heating. It has been tested and proven to heat the motorhome efficiently, reducing the operating time of the furnace blower assembly. The elimination of pre and post-purge cycling further enhances comfort and safety for occupants.
Additionally, the CheapHeat system offers versatility in heating options. It can be installed alongside existing propane or electric heating systems, allowing users to choose between propane or electricity as their preferred fuel source. This dual-fuel capability provides consistent warmth, whether connected to shore power or relying on propane while boondocking.
Parity and Forces: Strong vs Electric Interactions
You may want to see also
Frequently asked questions
You can convert an RV propane furnace to electric by purchasing an add-on module, such as the CheapHeat system by RV Comfort Systems. This system allows you to switch between propane and electricity to heat your RV.
Converting an RV propane furnace to electric offers several benefits, including:
- Reduced propane consumption and operating costs
- Elimination of cold air blowing during pre-cycling and post-cycle cool down
- Longer blower motor life
- Increased energy efficiency
- Enhanced comfort due to the elimination of pre and post-purge cycling
Before converting your RV propane furnace to electric, consider the following:
- Power requirements: Ensure that your motorhome can handle the power requirements of the electric coils.
- Shore power capabilities: When running the furnace in electric mode, you may need to run other appliances on propane to avoid tripping the circuit breaker.
- Safety: While the CheapHeat system is considered safe, always prioritize safety measures when dealing with electrical systems.
