Computers are made up of many components, but at the most fundamental level, they are built on transistors, which act as microscopic switches. These transistors can be combined to create logic gates, which perform basic mathematical operations and other functions that are essential for a computer to work. When electricity enters a computer, it flows through transistors, producing an output current. The Core Processing Unit (CPU) controls the voltage of electricity through many tiny circuits. High voltage can be considered on or 1, while low voltage is off or 0. By combining these currents and circuits, logic gates are formed, which can take two inputs in the form of two currents of electricity. These logic gates can be manipulated by a switch, which controls which gate is used and which 1's and 0's are fed into its input. This allows the computer to perform various functions and display information on a screen in a form that humans can understand.
| Characteristics | Values |
|---|---|
| Electricity input | Flow of electrical charge |
| Electricity path | Through a piece of wire due to a difference in electric field potential at each end |
| Voltage | High or low |
| Binary | High voltage = 1, Low voltage = 0 |
| Logic gates | Basic mathematical operations |
| Switch | Controls which logic gate is used and which 1s and 0s to feed into its input |
| Transistors | Microscopic switches that produce output current |
| Clock circuit | Controls the sequence of pulses |
| Multi-input AND gate | Checks multiple inputs to see if they are all 1s |
Explore related products
What You'll Learn
The role of the Core Processing Unit (CPU)
Electricity enters a computer via the power supply unit (PSU), which controls the distribution of electricity to the other components. One of these components is the Core Processing Unit (CPU), which acts as the computer's "'control center'" or "brain".
The CPU is a complex set of electronic circuitry that runs the machine's operating system and apps. It interprets, processes, and executes instructions from hardware and software programs. The CPU performs arithmetic, logic, and other operations to transform data input into more usable information output.
The CPU's principal components include the arithmetic-logic unit (ALU), which performs arithmetic and logic operations, processor registers, which supply operands to the ALU and store the results, and a control unit, which orchestrates the fetching, decoding, and execution of instructions by coordinating the operations of the ALU, registers, and other components.
The CPU also controls the voltage of electricity through many tiny circuits. High voltage can be considered "on" or "1", while low voltage is "off" or "0". By combining these currents and circuits, "logic gates" can be created, which can take two inputs (two currents of electricity) and determine whether to continue at high or low voltage.
Overall, the CPU is an essential component of a computer, handling every task the computer performs and making it possible to play, learn, and connect.
Electric CH Blast: Hitting Hard and Fast
You may want to see also
Explore related products
$189.99
Voltage control and logic gates
Computers use electricity to power logic gates, which are devices that perform Boolean functions, or logical operations, on binary inputs to produce single binary outputs. Logic gates are made from MOSFETs (metal–oxide–semiconductor field-effect transistors) and are designed to only input and output two types of signals: "high" (1) and "low" (0). These signals are represented by variable voltages, with full power supply voltage for "high" states and zero voltage for "low" states.
The Core Processing Unit (CPU) controls the voltage of electricity through many tiny circuits. High voltage can be considered "on" or "1", while low voltage means "off" or "0". By combining these currents and circuits, logic gates are created. Logic gates take two inputs, or two currents of electricity, and perform a logical operation on them. For example, an AND gate will only output a high voltage if both inputs are high.
Logic gates can be cascaded, allowing the construction of Boolean logic and algorithms. Compound logic gates such as AND-OR-Invert (AOI) and OR-AND-Invert (OAI) are commonly used in circuit design as they are simpler and more efficient than individual gates. Logic gates can be constructed using a variety of components, including vacuum tubes, electromagnetic relays, fluidic logic, pneumatic logic, optics, molecules, acoustics, and mechanical or thermal elements.
In reality, logic signal voltage levels rarely attain perfect voltage limits due to stray voltage drops in transistor circuitry. Logic gates have acceptable" input and output signal voltage ranges that they are designed to work with. For example, a TTL gate operates on a nominal power supply voltage of 5 volts, but can accept input signals ranging from 0 to 0.8 volts for a "low" logic state and 2 to 5 volts for a "high" logic state. If a voltage signal falls between these ranges, it is considered "uncertain", and the logic gate may not interpret it correctly.
