Conduit straps, also known as electrical conduit clamps, are an essential component of electrical installations, providing stability and safety. They are used to secure electrical conduits to walls, ceilings, or other structures, ensuring that conduits remain stable and properly aligned. When it comes to strap-mounted devices in electrical boxes, the National Electrical Code (NEC) guidelines specify that two conductors must be deducted for each device to prevent overcrowding and overheating, which can lead to electrical fires. The choice of strap and closing accessories depends on the specific installation requirements, such as the need to handle high vibrations or fix equipment of varying weights to electric poles.
| Characteristics | Values |
|---|---|
| Number of electrical conductors on a strap | Two |
| Strap material | Stainless steel |
| Strap thickness | 0.4mm or 0.7mm |
| Strap width | 10mm, 13mm, 16mm, or 20mm |
| Strap type | Two-hole straps, Minerallac straps |
| Strap function | Secure electrical conduits to walls, ceilings, or other structural surfaces |
Explore related products
What You'll Learn
National Electrical Code guidelines
The National Electrical Code (NEC), also known as NFPA 70, is the US standard for the safe installation of electrical systems. The National Fire Protection Agency (NFPA) publishes the residential electrical code book, which is updated every three years. The NEC outlines guidelines for outlets, boxes, grounding, GFCI and AFCI protection, and other parts of residential electric systems. While local codes usually adhere to the NEC, there may be variations, so it is important to consult local authorities before undertaking electrical work.
The NEC provides guidelines for the sizing and protection of branch-circuit conductors. The maximum permissible ampere rating or setting of the overcurrent protective device determines the branch-circuit rating. The ampacity of conductors must be considered, and the number of conductors in a raceway or cable can impact this. For example, Table 310.16 outlines the ampacities of N° 14, 12, 10, 8, and 6 AWG copper conductors. When there are more than three current-carrying conductors, adjustment factors come into play, reducing (derating) the ampacity. Tables 310.15(B)(1) and 310.15(B)(2) provide correction factors for ambient temperatures other than 30°C and 40°C, which must be applied before the adjustment factors.
The NEC also addresses specific requirements for certain types of cables and installations. For instance, Article 330 in the 2020 NEC covers Metal-Clad (MC) Cable, a commonly used product in the electrical industry. MC Cable is a factory assembly of one or more insulated circuit conductors enclosed in interlocking metal tape or a metal sheath. It is permitted in a variety of applications, including services, feeders, and branch circuits, and can be installed in assembly, hazardous, and plenum locations. The 2020 NEC also introduced Article 330.130, allowing for cable installations in hazardous locations, requiring the use of MC-HL cable, which has a gas/vapor-tight corrugated metallic sheath and a suitable polymeric jacket.
In addition to conductor sizing and cable types, the NEC provides guidelines for supporting and securing electrical conductors. For instance, PVC conduit must be secured within 3 feet of each outlet box, junction box, or other termination and supported every 3 feet for trade sizes ranging from 1/2 inch to 1 inch. The support distance increases with the conduit size; for instance, 2-inch PVC conduit can be supported every 5 feet, while 6-inch PVC conduit can be supported every 8 feet. Additionally, thermal expansion and contraction of PVC conduit due to temperature changes must be considered, and expansion fittings are required to protect the conductors inside the conduit.
