Building an electrical test bench is a great way to ensure you have the right equipment to test, configure and troubleshoot electrical components. The design of your test bench will depend on your needs, experience and budget. For example, a basic setup could include a folding table, hand tools and a cheap Digital MultiMeter (DMM). On the other hand, a more advanced setup might include a spare room with a full range of tools and accessories. Safety is a key consideration when building an electrical test bench, with some suggesting the inclusion of a 'deadman' switch to cut off the power supply in the event of an accident.
| Characteristics | Values |
|---|---|
| Purpose | To provide a safe and controlled place to work on electrical repairs and projects |
| Location | Not fixed; can be a simple folding table or a dedicated room depending on the user's needs and experience |
| Core Equipment | Multimeters, power supplies, soldering stations, hand tools, safety supplies |
| Power Supplies | Switch-mode DC power supply (SMPS) with variable voltage up to 10 A and 30 V |
| Safety Features | 10mA RCD breaker to limit shock hazard, "deadman" switch to cut off supply in case of accidental shock |
| Materials | Wood or melamine-faced board for the table, plywood for the structure |
| Use Cases | Testing and configuring smart home devices, light switches, dimmers, and relays; testing printed circuit boards |
Explore related products
What You'll Learn
Choose a suitable location and table material
When building an electrical test bench, it is important to choose a suitable location and table material. The location of your electrical test bench should be quiet and away from heavy foot traffic. Consider setting up your test bench in a heated garage, basement, or a small spare room. It is important to ensure that the chosen location remains fairly dry and does not experience large temperature swings, as this can affect the performance of your equipment.
If space is limited, consider a compact setup, such as a generous-sized workbench with compartments for parts and equipment storage. A wall-hinged drop-down table can also serve as a utility table when not in use, providing both functionality and aesthetics. Alternatively, you can opt for a shallow but wide closet or a folding table, depending on the available space and your specific needs.
When selecting the material for your test bench table, consider using wood, specifically a mortise and tenon softwood frame with aliphatic resin-glued stepped dowels for rigidity. For the tabletop, a 25mm medite board, glued and biscuit-jointed to the softwood frame, can provide a sturdy work surface. If you prefer a smoother finish, consider using hardwood for the frame and marine ply or hardwood for the tabletop.
Another option for the table material is to use a melamine-faced board, which is easy to clean and helps prevent tracking or discharge at mains voltages. This option provides a safer work surface for your electrical tests. Additionally, you can enhance safety by including a "deadman" switch, similar to a guitar pedal footswitch, which must be pressed to activate the supply contactor. This added safety measure can help protect you from electrical shocks.
