AutoCAD is a computer-aided design (CAD) software that enables users to create 2D and 3D drawings and models. An important feature of AutoCAD is the ability to use blocks, which are reusable collections of entities that can be inserted into a drawing as a single unit. The insertion point of a block is the location where the block is inserted into the drawing. This point is identified by a blue square in AutoCAD. In some cases, users may need to change the insertion point of a block, for example, to align it with a specific coordinate or to improve the placement of the block in the drawing. This can be achieved by using the Move command, entering specific coordinates, or utilising tools like Swap/Update Block or BASE to adjust the insertion point without exploding the block.
| Characteristics | Values |
|---|---|
| Editing an existing insertion point | Open the block file, enter BASE at the command line, and set it to 0,0,0 |
| Editing insertion point of an existing block | Launch the Move command, select the objects, and specify a base point for the insertion point. For the second point, enter 0,0. |
| Identifying insertion points | Hover over the point to display its position and name |
| Identifying reference points | Hover over the point to display its label name and position |
| Creating a new insertion point | Click New Insertion Point or type INSPOINT. Specify the location using the mouse or by typing in X,Y coordinates |
| Deleting an insertion point | Select the point and press Delete |
Explore related products
What You'll Learn
Editing the insertion point of existing blocks
When working with AutoCAD Electrical, you may encounter instances where the insertion point of a block doesn't meet your desired requirements. Here's a detailed guide on editing the insertion point of existing blocks:
Understanding the Issue:
In AutoCAD Electrical, the insertion point of a block refers to its specific location within a drawing file. In some cases, you may have blocks with insertion points that are not ideally positioned, such as having coordinates below 0,0. This can affect the overall layout and alignment of your design.
Editing the Insertion Point:
- Opening the Block File: Start by opening the block file that contains the insertion point you want to edit. This will allow you to access the block's properties and make changes.
- Using the MOVE Command: Launch the MOVE command within AutoCAD Electrical. This command allows you to select the objects within the block and manipulate their position.
- Specifying the Base Point: Once the MOVE command is activated, you can specify a base point for the insertion point of the block. Select the objects you want to adjust and choose the desired location for the new insertion point.
- Setting the Second Point of Displacement: After specifying the base point, you will be prompted to enter the coordinates for the "Second point of displacement." Enter 0,0 as the coordinates to align the insertion point with the origin (0,0) or specify any other desired coordinates.
- Saving the Changes: After making the necessary adjustments, click "Close Block Editor" and save your changes. This will update the insertion point of the selected block to the new coordinates you specified.
Additional Considerations:
- Existing Instances: Note that editing the insertion point of a block will not automatically update existing instances of that block in your drawing. To update existing instances, you will need to use the Swap/Update Block tool provided by AutoCAD Electrical.
- Block Editor Limitations: In some cases, you may find that the "`Block Editor`" option is greyed out or disabled. This could be due to an AutoCAD system variable (BLOCKEDITLOCK) that prevents users from editing blocks. You may need to adjust this setting to enable block editing.
- Temporary Insertion Point Changes: If you want to temporarily change the insertion point of a block without permanently altering its properties, you can use the "Insert" command. Type 'Insert' at the command line, choose your block, and specify the desired insertion point type (e.g., Basepoint).
By following these steps, you can easily edit the insertion point of existing blocks in AutoCAD Electrical, ensuring that your designs are accurately positioned and aligned.
