The mean electrical axis of the QRS complex is a clinically important aspect of ECG diagnostics, representing the average direction of the ventricular depolarisation wave in the frontal plane. It is also known as the ventricular axis and is determined by evaluating the vectors produced under the electrodes. The QRS complex is a spike in electrical current observed during ventricular depolarisation, which is detected by electrocardiography (ECG). The amplitude of an ECG R wave is proportional to how parallel the wave front of depolarisation is to the lead. To determine the mean electrical axis, a six-lead ECG is obtained from a patient, and there are multiple methods to estimate the axis, including the quadrant approach or 2-lead method, which involves examining leads I and aVF.
| Characteristics | Values |
|---|---|
| Definition | The mean electrical axis of the QRS complex in the ECG is the average direction of the ventricular depolarisation wave in the frontal plane. |
| Use | It is used to detect conduction abnormalities, ventricular hypertrophy, and the origin of arrhythmias. |
| Interpretation | Interpretation relies on determining the relationship between the QRS axis and limb leads of the ECG. |
| Normal axis | The normal adult QRS axis is between -30° and +90°, directed down and to the left. |
| Abnormal axis deviation | Left Axis Deviation = QRS axis less than -30°; Right Axis Deviation = QRS axis greater than +90°; Extreme Axis Deviation = QRS axis between -90° and 180°. |
| Paediatric ECG interpretation | The cardiac axis lies between +30 to +190 degrees at birth and moves leftward with age. |
| Determining the axis | Examine the QRS complex in each lead and determine if it is Positive, Isoelectric (Equiphasic) or Negative. The axis is determined by the relationship between these vectors. |
| Isoelectric lead | If a lead is isoelectric, the axis is perpendicular to that lead. |
| Positive QRS complex | A positive QRS complex in a lead has a ventricular axis approximately in the same direction as that lead. |
| Negative QRS complex | A negative QRS complex in a lead has a ventricular axis approximately in the opposite direction of that lead. |
| Multilead ECG | A multilead ECG helps rule out an artifact as the cause of electrocardiographic abnormalities seen in a single-lead tracing. |
