Electric train sets are a fun and intricate hobby, but sometimes they need to be disassembled for maintenance or storage. Whether you're a beginner or an experienced model railroader, the process of taking apart an electric train set can be daunting, but with the right tools and knowledge, it's achievable. This guide will walk you through the essentials of disassembling an electric train set, including the necessary skills, tools, and step-by-step instructions to make the process smoother. From removing the draft-gear boxes and couplers to separating the shell from the body, we'll cover everything you need to know to confidently tackle this task and ensure your train is ready for its next adventure on the tracks.
| Characteristics | Values |
|---|---|
| Locomotive disassembly essentials | Remove the draft-gear boxes and couplers, separate the shell from the body, and remove the trucks. |
| Tools | Foam cradle, screwdrivers in various sizes, a metal grabber pickup tool, and hobby knives with Nos. 11 and 17 blades |
| Common train set components | Locomotive, freight or passenger cars, sections of track, transformer |
| Electric train dangers | Severe electric shock if the transformer does not reduce the voltage to a safe level |
| Issues with plastic train parts | Warping and disfigurement from heat, leading to cracks and breaks in the insulation around wires |
Explore related products
What You'll Learn
Removing the shell
First, remove the draft-gear boxes and couplers. Typically, the front and rear boxes are secured with a single Phillips-head screw. After removing the screw, gently pull out the boxes and couplers, being careful not to misplace the small parts. Place them in a container or utilise the recess in your foam cradle to keep them organised and safe.
Next, locate the screws that hold the shell to the mechanism. On some models, like the WalthersMainline EMD SD50, there are two shell screws found between the fuel tank and the front of the rear truck. You may need to slightly rotate the truck to access these screws. Remember to use the correct screwdriver to avoid damaging the screws.
Once the shell screws are removed, it's time to separate the shell from the body. Hold the locomotive in your right hand and make a fist with your left hand. Lightly tap the shell from below the front pilot, then repeat the same action on the back pilot. This should release the shell from the mechanism without causing any damage.
In some cases, you may need to break glue joints to fully remove the shell. For this step, a hobby knife with a No. 17 blade is useful. Exercise caution when working around clear plastic parts to avoid any accidental cracks or breaks.
Electrical Code and Arc Fault Breakers: What's the Requirement?
You may want to see also
Explore related products
Taking out the draft-gear boxes and couplers
To begin disassembling an enormous electric train set, you'll first need to remove the draft-gear boxes and couplers. The coupler is a mechanism that connects the rail vehicles, and the draft gear or draw gear absorbs the stresses of the coupling and the train's acceleration.
The first step is to locate the front and rear draft-gear boxes, which are usually secured with a single Phillips-head screw. Using a Phillips-head screwdriver, remove the screw and gently pull the boxes, along with the attached couplers, out of their housing. It is important to place these screws, boxes, and couplers in a container to avoid misplacing them during the disassembly process. Removing these components is generally straightforward and can be accomplished with relative ease.
The next step is to identify the screws that hold the shell to the mechanism. Depending on the train model, you may need to slightly rotate the truck to access these screws. On a WalthersMainline EMD SD50, for instance, there are two shell screws located between the fuel tank and the front of the rear truck. These screws have a coarse thread because they are designed to mount into plastic. Carefully remove these screws and set them aside in the container to keep them organised and easily accessible during reassembly.
At this stage, you may also need to address the coupler height and shim the coupler box with thin styrene sheets to ensure it meets the standard coupler height. This process involves using a coupler height gauge and adjusting the coupler box accordingly. Additionally, you might consider using a magnetic screwdriver to tighten down the screws near the draft-gear boxes, reconnecting the plugs to the motherboard.
Once you have removed the necessary screws and adjusted the coupler height, you can safely remove the draft-gear boxes and couplers. It is important to handle these components with care and place them in a secure location, as they are crucial for reassembling your train set. Remember to test the locomotive after reassembly to ensure all functions are operating correctly.
