Electricians have several methods to pull wire through a conduit, including the fishing weight method, fish tape, or string. The fishing weight method involves tying a heavy fishing weight to the end of the wire using string or fishing wire, giving the weight a 2- to 3-inch lead in front of the wiring. The weight is then placed inside the conduit, and the wire is adjusted so it can move behind the weight. The weight is dropped, and gravity pulls the weight along. Fish tape is a long, flat metal wire wound inside a wheel-shaped spool, which is fed into the conduit and pushed through, unwinding as it goes. The type of conduit will determine the best method for pulling wire through it, and the process can be challenging for long or complex conduit paths.
| Characteristics | Values |
|---|---|
| Purpose | To house and protect electrical wires within a building or structure |
| Types | Rigid Metal Conduit (RMC), Intermediate Metal Conduit (IMC), Electrical Metallic Tubing (EMT), Electrical Non-Metallic Tubing (ENT), Flexible Metal Conduit (FMT), Liquid-tight Flexible Metal Conduit (LFMC) |
| Materials | Metal, Plastic, Galvanized Steel, Coated Steel, Stainless Steel, Aluminum |
| Applications | Residential, Commercial, Industrial, Outdoor, Indoor |
| Benefits | Protection, Safety, Durability, Ease of Installation, Cost-effectiveness, Flexibility, Corrosion Resistance, Fire Resistance |
| Considerations | Wall Thickness, Mechanical Stiffness, Material Cost, Installation Cost, Wiring Regulations, National Electrical Code (NEC), Local Code Requirements |
| Installation Steps | Chalk out wiring plan, Measure conduit length, Make bends, Attach fittings to wall, Secure conduit, Tape ends, Pull wires |
| Tools | Conduit Bender, Hacksaw, Screwdriver, Slip-joint Pliers, Fish Tape |
Explore related products
What You'll Learn
Understand the different types of conduits
Electrical conduits are essential for wiring jobs, protecting electrical cables from damage in exposed areas. They are classified by wall thickness, mechanical stiffness, and material.
Conduits can be rigid or flexible and are typically made of metal or plastic. Metal conduits can be further divided into rigid metal conduits (RMC), intermediate metal conduits (IMC), and flexible metal conduits (FMT). RMCs are thick-walled threaded tubing typically made of stainless steel, coated steel, or aluminium. IMCs are similar but lighter than RMCs. FMTs are made from spirally constructed interlocking metal bands, allowing the conduit to bend easily for installation in walls or other structures.
Non-metal conduits are typically made of plastic. Electrical non-metallic tubing (ENT) is a flexible, plastic, corrugated tubing that is flame-retardant and moisture-resistant. It is less expensive than metal conduits but still capable of protecting wires and cables from abrasion and light damage.
Another type of conduit is electrical metallic tubing (EMT), which is commonly used instead of galvanized rigid conduit (GRC) as it is less costly and lighter. EMT is typically made of coated steel or aluminium and is available in various colours for easy system identification. EMT is strong, cheap, and easy to bend with a special tool, though it requires fittings and couplings to connect pieces together. EMT is generally used for indoor wiring in commercial and residential buildings, though it can be used outdoors with watertight industrial fittings.
Other types of conduits include HDPE, which is a durable, impact-resistant, and low-cost plastic conduit; liquid-tight flexible metal conduit (LFMC), which has a sealed plastic coating to make it watertight and corrosion-resistant; and rigid PVC conduit, which is a low-cost material that protects wires from abrasion and light damage.
Electricity's Intriguing Similarities: Unveiling the Common Threads
You may want to see also
Explore related products
Learn how to pull wire through a conduit
Pulling wire through an electrical conduit is a challenging task that often requires at least two people. Electrical conduits are tubes that protect and route electrical wires, and they can be hundreds of feet long. To pull wires through, you will need tools like a wire mouse, fish tape, string, or a fishing weight. Here is a step-by-step guide on how to pull wire through a conduit:
Prepare the Wire and Conduit
Before beginning, ensure you have the necessary tools, including a lubricant, wire mouse or conduit piston, strong string or pull string, and a shop vacuum. Prepare the wire by stripping insulation from the end of each wire using wire strippers. Strip each wire a different amount to distinguish them. For example, if there are three wires, strip one about six inches, another about four inches, and the last one about two inches. Then, grab all the wires with linesman's pliers and twist their bare ends together to align their insulation.
Use a Lubricant
Apply a lubricant, such as a wire-pulling compound, to the wires to make it easier to slide them through the conduit. Bends and friction with other wires can make wire-pulling challenging, so the lubricant will help by coating the wire and making it slick. Apply more lubricant at the beginning of the pull, and less towards the end, as the interior of the conduit will become coated as you pull.
Use a Fish Tape or String Method
Fish tape is an electrician's tool with a long, flat metal wire wound inside a wheel-shaped spool. Feed one end of the fish tape, which has a hook, into the conduit. Stop feeding when the hook end emerges from the opposite end of the conduit. Bend the longest wire into a hook and loop it through the hook of the fish tape. Wrap the loop closed and secure it with electrical tape.
Alternatively, the string method works well for short, straight conduits. Tie a long, strong string to a long, thin, rigid rod. Push the rod into the conduit with the tied end first. Once the tied end emerges from the other end, tie the electrical wire to the loose end of the string. Pull the rod from the conduit's end, pulling the wire through.
Pull the Wire Through
With the fish tape method, apply lubricant to the tape and wires, if desired. Feed the wires into the conduit from the starting end. Have another person at the other end to help pull the wires through by pulling on the fish tape.
For long conduits, it may be helpful to use a shop vacuum to suck the rope or string through the conduit. This is not a one-person job, so ensure you have assistance. Cut the rope with some slack and attach it to the wire securely with high-quality electrical tape. Have one person push the wire into the conduit while two people pull on the rope at the other end.
Additional Tips
If you encounter resistance or the wire feels stuck, try using cable-pulling lubes, hot water and soap, or a combination of boiling water, soap, and air pressure to help loosen the wire. For long conduits, communication tools like walkie-talkies are essential. Patience is key to avoiding a broken wire.
