Electrical feeder schedules are an important aspect of electrical design and installation, providing essential information for professionals in the field. Feeder conductors are responsible for delivering electricity within a house, taking over after the service entrance to supply power to the branch circuits. Before installation, a feeder diagram is often required, detailing the load, demand factors, size, type of conductors, and rating of overcurrent protective devices. Understanding how to read a feeder schedule is crucial for ensuring proper sizing of cables and conductors, considering voltage drop and equipment grounding. It also aids in quick identification of phase and voltage by qualified personnel. Creating a custom schedule with relevant parameters can be automated using tools like Revit MEP, aiding in efficient electrical feeder scheduling.
| Characteristics | Values |
|---|---|
| Purpose | To provide fundamental information for electrical design tasks and calculations |
| Information Included | Feeder sizes, overcurrent protective device ratings, wire sizes, voltage drop, equipment grounding conductor size, feeder type and load |
| Use | Allows qualified persons to quickly identify the phase and voltage of feeder conductors |
| Creation | Can be created using electrical add-ins for Revit MEP |
Explore related products
What You'll Learn
Understand the difference between service and branch circuit conductors and feeder conductors
Conductors are wires that carry electricity. Feeder conductors are those that are neither service conductors nor branch circuit conductors. They deliver electricity within a house, taking over from the service entrance, which brings power from the utility pole, and supplying power to the branch circuits.
Service conductors are those between the utility service point and the service disconnecting means. They are not feeder conductors, and special service conductor rules apply because these conductors do not have short-circuit or overload protection.
Branch circuit conductors are those between the final overcurrent device protecting the circuit and the outlet(s). They have a smaller current flow than feeder conductors.
Feeder conductors are the "middle set" of conductors in the power distribution scheme. They are the circuit conductors between the service equipment, the source of a separately derived system, or other power supply source and the final branch-circuit overcurrent device. They are sized differently from branch circuit conductors. With branch circuits, the OCPD size is known, and the conductor is sized accordingly. With feeders, the load is determined, and then the conductor and OCPD are sized accordingly.
Feeder circuits must include an equipment grounding conductor (EGC) of a type listed in Sec. 250.118. The EGC must be installed in a way that allows branch-circuit EGCs to connect to it.
