Kenmore, a trusted household brand, has been manufacturing appliances since 1913. Their first automatic electric clothes dryer was released in 1949. Kenmore dryers are known for their Wrinkle Guard and Sensor Dry technology. As with any appliance, issues may arise that require troubleshooting and repairs. Common problems with Kenmore dryers include failure to start, which could be due to various issues such as power supply problems, a faulty door switch, or a defective control board. Other issues may involve specific parts like the drive belt, motor relay, or thermal fuse. To accurately identify the issue and perform repairs, it's essential to understand the model number and refer to repair guides, manuals, and step-by-step instructions available online.
| Characteristics | Values |
|---|---|
| First Step | Check the power source, including the outlet, plug, power cord, and electrical panel. |
| Common Issues | Circuit breaker tripping, door switch issues, control board problems, power cord faults, wiring failures, blown thermal fuse, etc. |
| Parts Replaced | Fuse, thermal fuse, breaker, control valve, gasket, seal, grille, kickplate, heating element, etc. |
| Model Identification | Model number found inside the dryer, around the drum, or on the door. Common models: 65132, 69133, 81382. |
| Online Resources | Sears PartsDirect, iFixit, Repair Clinic, Sears Home Services, etc. |
Explore related products
![[Newest] 4392067 Dryer Repair Kit and W10837240 Dryer Idler Pulley for Maytag Bravos Whirlpool Duet Kenmore Elite Dryers,with WPW10314173 Drum Roller&661570V Belt&279640 Idler Pulley by TOMOON](https://m.media-amazon.com/images/I/71wJfNcwc0L._AC_UY218_.jpg)
What You'll Learn
Identify the model number
To repair your Kenmore electric dryer, the first step is to identify the model number. The model number is important because it allows you to accurately identify the specific features and manufacturing details of your dryer. This is key when it comes to procuring the right parts and services for your appliance.
The model number of your Kenmore dryer can be found inside the dryer, around the drum, or on the door. Common models include the 65132, 69133, and the 81382. The model number consists of various parts, each indicating different aspects of the appliance, such as the source code, model year, and feature level.
By matching the prefix of your model number with a detailed table, you can uncover the original manufacturer. This is a crucial step in the repair process, as it helps you find the right parts for your dryer. Kenmore appliances are manufactured by several leading companies, so it is important to identify the correct manufacturer for your specific model.
The model number of your Kenmore electric dryer is the key to navigating the complex world of appliance repair and maintenance. Each model has unique features and manufacturing details, so understanding the model number designation is essential for accurate and efficient troubleshooting.
Electric Machine Importing: Navigating the USA Process
You may want to see also
Explore related products
Check the power source
If your Kenmore dryer won't start, the first place to check is the power source. A lack of electrical power could be due to a bad power cord, wiring failure, or other issues.
First, inspect the outlet. Make sure the plug is not loose and that the power cord is not damaged. Try plugging a different device into the outlet to confirm that the outlet itself is functional. If your dryer uses a GFCI outlet (Ground Fault Circuit Interrupter), press the reset button on the outlet to restore power.
If everything is fine at the outlet, your next step is to check your home's electrical panel. These are usually located in the basement, hallway, or garage. Inspect the panel for a tripped circuit breaker. If you're not sure which breaker corresponds to your dryer, look for one that is in a different position from the others. Flip the breaker back to the "on" position, then return to your dryer and test if this has fixed the problem.
If your dryer is frequently tripping the circuit breaker, this could indicate a more serious electrical problem. Check that there aren't too many appliances plugged into the same circuit, or consult an electrician to get to the root of the problem.
If you've ruled out any electrical issues, try resetting your Kenmore dryer. If your dryer has experienced a technical glitch or power surge, it can freeze, meaning you won't be able to start it. To reset your dryer, unplug it or trip the circuit breaker. Leave your dryer disconnected from the power for at least two minutes. Restore power to your dryer and test if it starts.
Creating Estimates with AutoCAD Electrical: A Step-by-Step Guide
You may want to see also
Explore related products
Reset the control board
To reset the control board of your Kenmore electric dryer, start by unplugging the dryer from the power source. This is important to prevent any risk of electrical injury or damage to the appliance. Once it's unplugged, you can proceed to remove the top panel by unscrewing it from the rear of the appliance. Slide and lift the panel off.
The next step is to remove the control panel. Do this by first freeing the knobs so that the panel can slide free of the control switch shafts. Then, remove the screws securing the control panel in place. With the control panel removed, you'll have access to the wire harnesses attached to the circuit board. Disconnect these wires by compressing any push tabs and slipping the wires free.
Now, with a clear view of the control board, remove the screws holding it in place. Gently pull the bottom edge of the control panel down to release the locking tabs. At this point, you can lift the control board out of the shell of the control panel. If you intend to replace the control board, this is when you would insert the new one, being careful to align the matching parts.
Once any necessary adjustments or replacements have been made, carefully follow the disassembly steps in reverse to reassemble the dryer. Ensure that the control board is securely in place and that all buttons are aligned. Finally, push the dryer back into position and plug it in. Test the control board by pushing the buttons to ensure they're now functional.
Relocating Electrical Wiring: A DIY Guide to Moving Outlets
You may want to see also
Explore related products
Replace the drive belt
To replace the drive belt on a Kenmore electric dryer, start by unplugging the electrical cord from the outlet and turning off power to the circuit. Remove the lint trap and the screws securing the lint trap cover with a Phillips-head screwdriver. Slide a putty knife into the seam between the dryer's top and cabinet and pry it up to pop the top free of its spring clips. Rotate the top up and backward, then unplug the door switch wire connector inside the cabinet. Next, remove the front panel mounting screws and pull the front panel off of the dryer. Pull the broken belt out of the dryer and lift the front of the drum to access the drive motor and idler pulley.
Position the new drive belt on the dryer drum, then thread the drive belt through the idler pulley. Push the idler pulley to the right and loop the drive belt over the motor pulley. Position the front panel on the hangers at the bottom of the dryer and line up the mounting holes. Reinstall the screws in the top of the front panel to secure it to the dryer. Plug the wire harness back into the plug on the door switch and make sure the locking tab engages properly.
Finally, turn the drum by hand to ensure the belt is tracking straight with no twists or kinks. Reinstall the front panel and reconnect the door switch. Lower the top panel and push down firmly to seat it into the spring clips. Secure the lint trap cover in place with the two screws and replace the trap. Switch the circuit breaker back on, then plug in the electrical cord and start the dryer to test for function.
Pricing Large Electrical Jobs: A Comprehensive Guide
You may want to see also
Explore related products
![BlueStars [LIFETIME WARRANTY] 3387134 Cycling Thermostat 3392519 Dryer Thermal Fuse 3977393 Thermal Cut-off Switch 3977767 High-limit Thermostat Kit - Compatible with Whirlpool Kenmore Maytag Dryers](https://m.media-amazon.com/images/I/81FYRO8xJjL._AC_UY218_.jpg)
Check the door switch
To check the door switch of your Kenmore electric dryer, first identify if the switch is faulty. If the light does not come on when you open the dryer door, it could be that the light is burned out. However, if the dryer does not stop when the door is opened, and the light does not come on, it is likely that the door switch is broken.
Once you have identified that the door switch is broken, you can remove the lint filter and unscrew the two Philips screws located underneath it. Next, gently separate the top of the dryer from the body, which may require some force. Do the same on the other side, and lift the top up. You should now be able to see the door switch. Note its orientation, as you will want to install the replacement switch in the same direction.
Remove the two screws holding the switch in place, and lift the switch up from the dryer frame. Unplug the old switch, and plug in the new replacement switch. Insert the new switch into the frame from the top of the dryer, and replace the two screws that hold it in place. Close the top of the dryer, and replace the two screws that were under the lint filter.
Finally, plug the dryer back in, and turn the power back on. Your dryer should now be functioning properly with a new door switch.
Choosing the Perfect Electric Winch for Your Camper
You may want to see also
Frequently asked questions
The first place to check is the power source. Inspect the outlet and make sure the plug is secure and the power cord is not damaged. Try plugging a different device into the outlet to ensure it is functional. If your dryer uses a GFCI outlet, press the reset button. If the outlet is fine, check your home's electrical panel for a tripped circuit breaker.
There could be an issue with the control board of your Kenmore dryer. The control board is like the "brain" of the dryer, controlling all its commands and functions. If it's faulty, the dryer may not start. You will need to replace the entire control board, which is a complicated electrical job, so consider hiring a professional.
Some other common issues include a broken heating element, tripped safety thermostat or fuse, bad drum support roller, damaged idler pulley, clogged exhaust vent, loose dryer door catch, control system failure, and blown thermal fuse.
You can find replacement parts for Kenmore dryers on websites such as repairclinic.com, fleetappliance.com, and searspartsdirect.com. These websites also offer repair guides, troubleshooting tips, and step-by-step instructions to help you fix your dryer.
