Repairing an underground electrical line can be a challenging task due to the high voltage involved and the potential dangers associated with it. It is essential to exercise extreme caution and follow safety protocols to ensure a successful repair. The first step is to locate the break in the underground line, which can be done with the help of an electrician using specialised equipment such as ground-penetrating radar or time-domain reflectometry. Once the break is located, the next step is to excavate the area and expose the damaged cable. At this point, it is crucial to turn off the main electrical supply to prevent any accidents. The repair process typically involves using an underground splice kit, which comes in two varieties: heat-shrinkable tubing and gel-filled shields. These kits provide a water-resistant connection and protect the splice from corrosion and moisture. It is important to closely follow the manufacturer's instructions when using these kits. In some cases, it may be necessary to replace the entire section of the damaged cable with a new one of the same gauge. This process requires cutting, stripping, and properly connecting the wires using the splice kit.
| Characteristics | Values |
|---|---|
| First Steps | Turn off the main electrical supply before attempting any repair. |
| Locating the Fault | If the location of the break is unknown, hire an electrician with an underground open/short locator. Alternatively, try ground-penetrating radar, time-domain reflectometry, or a device called a thumper. |
| Repair Method | Use an underground splice kit, which typically includes heat-shrinkable tubing and a gel-filled shield. For low-voltage wiring, use low-voltage connectors for direct burial. |
| Additional Tips | Purchase waterproof junction boxes to protect connections from corrosion due to moisture. Ensure the wiring is deep enough to avoid damage from gardening tools. |
Explore related products
What You'll Learn
Locating the fault
Cable Thumping:
This method involves using a cable thumper or surge generator to inject a high-voltage DC surge into the faulty cable. The surge creates a high-current arc at the exact location of the fault, producing a characteristic thumping sound. By repeatedly thumping and walking along the cable route, the fault can be located. Cable thumping is accurate and easy to apply and learn. However, it can be time-consuming for longer cables and may weaken the insulation of the cable due to frequent high-voltage surges.
Time Domain Reflectometry (TDR):
TDR sends a low-energy signal into the cable, causing no degradation to the cable insulation. It works well for open-circuit faults and conductor-to-conductor shorts. However, TDR provides an approximate distance to the fault location rather than an exact pinpoint and may be affected by surrounding electrical noise.
A-Frame Fault Finder:
Technicians use this equipment to locate the exact place that needs repair and indicate the severity of the fault. It works by applying an 8K frequency to the power or telecom cable.
Section Testing:
Crews isolate a section of the cable and apply a DC hipot voltage. If the cable holds the voltage, they move on to the next section until they find a cable that cannot hold it. A faster variation involves using high-voltage sticks that apply a DC voltage to the isolated section.
VLF HI-POT TEST:
This method is suitable for long-length cables. It involves applying a very low frequency (VLF) voltage to the cable for a specified duration. The voltage and frequency values depend on the cable's specifications.
Murray and Varley Loop Tests:
These are popular techniques for locating faults in underground cables, but specific details about their implementation are not readily available.
It is important to note that locating underground cable faults requires specialized equipment and expertise. Engaging professionals with the right tools, such as The Underground Detective or electrical professionals, can save time and money by accurately pinpointing the location of the fault.
