The General Electric Microwave JE2160SF03 is a popular model that has been in use for many years. However, some users have experienced issues with their microwaves not heating food or liquids. Common causes for this issue include a faulty diode, magnetron, or thermostat magnetron. In some cases, the issue may be as simple as a loose wire. To repair this microwave model, users can refer to online resources that provide repair help, videos, and official parts for their exact model.
| Characteristics | Values |
|---|---|
| Model Number | JE2160SF03 |
| Manufacturer | General Electric |
| Age | 16 years |
| Part Replacements | Diode (PS953843), Magnetron (PS953838), Thermostat Magnetron, Sensor |
| Repair Steps | Discharge transformer's capacitor, check capacitor and diode, order parts, attach sensor to new magnetron, connect harness from transformer to new magnetron |
| Tools | Multimeter, wrench |
Explore related products
What You'll Learn
Replacing the diode
Before attempting any microwave repair, it is important to discharge the transformer's capacitor. Once this is done, you can open the diagram/schematic found inside the microwave oven and follow the technician's troubleshooting steps.
The diode is an electrical current control device inside the microwave. It provides high voltage that powers the magnetron. You may need to replace it to fix the issue. The diode's part number is PS953843.
To replace the diode, you will need to remove the cover of the microwave. On the back of the appliance, there will be screws holding the cover in place. Once the cover is removed, you will be able to access the diode and replace it with a new one.
It is recommended to check the diode before replacing it, as sometimes the issue may lie elsewhere. In some cases, replacing the diode may not solve the problem, and other parts such as the magnetron or thermostat magnetron may need to be replaced as well.
