The gauge of a wire refers to its diameter and thickness, with smaller numbers representing thicker wires and larger numbers indicating thinner ones. It is important to know the gauge of a wire as it tells an electrician how much electrical current a wire can carry without heating up. If a wire carries a higher current than it is rated for, it can lead to wire deterioration and an increased risk of an electrical fire. There are several ways to determine the gauge of a wire, including using a wire stripper, which has round holes with AWG sizes mentioned over them, or by measuring the diameter of a single wire strand in either millimetres or inches.
| Characteristics | Values |
|---|---|
| Wire gauge | Refers to the wire's diameter or thickness |
| Wire gauge indication | The wire's insulation indicates the American Wire Gauge (AWG) sizes of the wires |
| Cable colour | Indicates the polarity of the wire (whether neutral or hot) |
| Ampacity | The maximum amperage a wire can conduct before it overheats |
| AWG and ampacity | A lower gauge wire will have a higher-rated ampacity |
| Wire strippers | Can be used to determine the wire's diameter or AWG size |
| Wire strippers holes | The number stamped by the hole on the wire stripper indicates the gauge size of the wire |
| Wire gauge calculation | The gauge of stranded wire is calculated by multiplying the diameter of a single wire strand by itself and by the number of strands |
Explore related products
What You'll Learn
Use a wire stripper to determine the wire's diameter or AWG size
Using a wire stripper is a common way to determine the AWG size of a wire. The wire stripper is a tool designed to remove the thin plastic coating from a wire, but it can also be used to determine the gauge size. Most wire strippers have a series of round holes labelled with AWG sizes, into which the wire can be inserted.
To use the wire stripper to determine the wire's AWG size, first estimate the approximate size of the wire. This will save time by avoiding the need to test the wire in excessively large or small holes. Next, insert the wire into the hole that is the closest match to the wire's size. The wire should fit into the hole with ease, but the hole should not be too large. If the wire passes through the hole with force, the hole is too small. The number stamped by the hole that the wire fits into will indicate the gauge size of the wire.
It is important to note that the diameter measurement will not be an exact gauge size, as only uninsulated solid wires are gauged. Additionally, stranded wire diameters can vary depending on factors such as the number of strands, the amount of twist, and manufacturing processes. Therefore, it is recommended to consult the manufacturer of the wire or a hardware store for more accurate information.
Alternatively, there are other tools that can be used to determine the wire's diameter or AWG size. These include a wire and conduit measuring device, a micrometer, calipers, or a wire-gauge tool.
