The Chicago Electric 10-inch Sliding Compound Miter Saw is a versatile and affordable tool used for making quick, accurate crosscuts and miters in wood. It is suitable for both professionals and home DIYers. This miter saw offers a range of adjustments, including miter, bevel, fence tilt, and slide adjustments, to achieve precise cuts. The saw comes with a 10-inch carbide-tipped blade that can cut through various materials, such as wood, plastic, and thin metals. Proper maintenance, including regular cleaning, blade alignment checks, and part replacements, is crucial to ensure the saw's accuracy and longevity.
| Characteristics | Values |
|---|---|
| Blade size | 10-inch carbide-tipped blade |
| Cutting capacity | 12-inch crosscut capacity, 3-5/8-inch vertical cutting capacity, 2x8-inch bevel cutting capacity |
| Motor | 15-amp motor with a no-load speed of 4,800 RPM |
| Miter adjustment | 0°, 15°, 22.5°, 31.6°, and 45° left and right |
| Bevel adjustment | 0°, 15°, 22.5°, 31.6°, and 45° left |
| Fence tilt | Up to 47° in both left and right directions |
| Slide adjustment | Smooth sliding fence for precise alignment of cuts up to 12 inches wide |
| Uses | Precise cuts in wood, plastic, and some metals |
| Maintenance | Regular cleaning, lubrication of moving parts, and blade replacement as needed |
