Testing an electric boiler valve can be done in several ways, depending on the type of boiler and valve. One common method is to use a multimeter to test the voltage at the valve, which can help identify if the breaker is powering the valve and thermostat. Another method is to check the current with a current clamp, which can indicate if the heating elements are functioning correctly. For safety valves, annual testing is recommended, but caution must be taken as poor-quality valves may leak after testing. Before testing, it is important to disconnect the supply cables and ensure the boiler is safe. If issues are identified, further investigation or professional assistance may be required.
| Characteristics | Values |
|---|---|
| Testing a zone valve on a boiler | Turn up the thermostat, wait for several minutes, then push the lever to the manual open position. If there is no resistance, the valve is open. |
| Testing a boiler relief valve | Low-pressure steam boiler relief valves should be tested when the pressure is at 75% of the relief valve setting, which is 11 Psig. |
| Testing a boiler circuit breaker | Check for 24VAC at the zone valves with a multimeter. |
| Troubleshooting an electric boiler | Disconnect the supply cables from the terminals and re-energise the supply circuit. If the RCD trips, the issue is likely with external wiring. If the RCD holds, the fault is within the boiler and caused by a failed element. |
| Troubleshooting a boiler that is not heating water | An electrician can use a current clamp to measure the current being drawn by the boiler. A lower reading than expected could indicate that one or more heating elements have expired. |
Explore related products
What You'll Learn
Check the current with a current clamp
Checking the current with a current clamp is a test an electrician can perform to identify issues with an electric boiler that is powered but not heating up water. This issue is usually caused by a problem with a heating element.
To check the current with a current clamp, an electrician will place the clamp over the live supply cable (or cables in a three-phase installation) and record the reading the meter gives. The meter reading should then be checked against the expected current values in the data table in the boiler's instruction manual.
If the current reading is lower than expected, this could indicate that one or more of the heating elements within the boiler may have expired. To verify this, the electrician will isolate the supply to the boiler and measure the resistance of each of the heating elements in turn.
If the current reading is higher than expected, this could indicate a short circuit or a faulty component. In this case, the electrician will need to further investigate the issue to identify the cause.
It is important to note that any electrical work must be carried out by a competent person, ideally a professional. Homeowners who are confident with electrics and able to isolate the electrical supply can also perform this test, but it is crucial to prioritize safety and follow instructions carefully.
