Electric grill elements are found in ovens and cookers, and they can be tested for faults in several ways. One common method is to perform a continuity test using a multimeter or a Megger insulation tester, which can detect faults that a standard multimeter might miss. This involves measuring the electrical resistance of the grill element by attaching probes to the metalwork and electrical connectors. Another way to test an electric grill element is to inspect it physically for any signs of damage or wear and tear, such as grease spots, which can cause the element to malfunction. Regular cleaning can help prolong the life of the grill element by preventing a buildup of dirt and grease. Additionally, when heating the oven, the heating element should glow orange within about 10 minutes, indicating that it is functioning correctly. If the element doesn't glow or only partially glows, it may need to be replaced.
| Characteristics | Values |
|---|---|
| Testing equipment | Multimeter, Megger or Insulation tester |
| Multimeter settings | Voltage (V), Resistance (mAVΩ), Current (A) |
| Multimeter procedure | Plug in the red and black cords, turn the dial to the lowest ohm setting, place the heating element on a grounded surface, calibrate the multimeter by touching the metal probes together, touch the probes to the element's terminals |
| Megger procedure | Attach one probe to the metalwork of the component, attach the second probe to the electrical connector on the element, press test |
| Fault identification | No reading on multimeter, low resistance reading on Megger |
| Other tests | Visual inspection, cross-checking temperature with an oven thermometer |
| Preventative measures | Regular cleaning, avoiding abrasive cleaners and aluminium foil lining, sparing use of self-cleaning feature |
Explore related products
What You'll Learn
Using a multimeter to test continuity
To test an electric grill element with a multimeter, you will need to perform a continuity test. This will allow you to determine whether the element is receiving electrical signals correctly. Before you begin, ensure that your grill is switched off and disconnected from the mains. If your grill is wired in and cannot be unplugged, turn it off at the switch and also turn off the switch powering it in your fuse box.
Now, remove the grill element from your grill. Place the element on the floor or on a wooden table or another grounded surface. Ensure that you do not place it on a metal or ungrounded surface, as you may electrocute yourself.
Next, set up your multimeter. Plug the black wire connection into the black socket and the red wire connection into the red socket. Then, set the multimeter to the continuity setting. Turn the dial to the lowest number in the ohm range (usually 200 ohms). Some multimeters have an ohms setting with an audible alarm, which can be useful. Now, turn the multimeter on.
Before testing the grill element, calibrate the multimeter by touching the metal probes together. The probes are the little metal prongs sticking out of the end of each wire. If the number on the screen is lower than 1.0, your wires are functioning correctly. If the number is higher, try cleaning the terminals and testing again.
Finally, test the grill element. Take the two probes and press them against the two small tabs protruding from the heating element. If your multimeter emits a high-pitched beep, the element is working fine. If there is no beep, the element is faulty and needs to be replaced.
