A multimeter is a small electronic device used to measure electrical properties such as voltage, current, and resistance. It can be purchased at a home improvement store, hardware store, or anywhere tools are sold. When testing an electrical plug with a multimeter, it is important to first set the multimeter to measure voltage. Then, insert a probe into each slot and read the voltage measurement. A properly working outlet should give a reading of 110 to 120 volts. If there is no reading, the wiring and outlet should be checked. It is also important to always plug in the neutral wire first when testing an outlet with a multimeter to avoid electrical shocks.
| Characteristics | Values |
|---|---|
| What is a multimeter used for? | Measuring electrical properties such as voltage, current, and resistance. |
| What to do before testing? | Turn off the power. |
| How to test voltage? | Set the multimeter to measure voltage. Insert a probe into each slot and read the line voltage measurement. |
| What is a good voltage reading? | A reading of 110 to 120 volts indicates a properly working outlet. |
| How to test if the outlet is grounded? | Insert one probe into the small outlet slot and the other probe into the receptacle's center screw. |
| What to do if the outlet is not grounded? | Conduct a polarity test to check if the wires are reversed. |
| How to conduct a polarity test? | Insert one probe into the large slot and the other against the screw. |
| How to determine the hot cable? | Turn off the power, then disconnect the outlet and place caps on all wires except one black wire. Turn the power back on and touch a probe to the ground wire and the other probe to the black wire. |
| Any safety precautions? | Always plug in the neutral wire first to avoid a shock. Hold both meter probes in the same hand to avoid an electric shock. |
Explore related products
$21.98 $24.97
What You'll Learn
How to measure voltage
To test an electrical plug with a multimeter, you can measure the voltage. A multimeter is a small electronic device used to measure electrical properties such as voltage, current, and resistance. It is sometimes also known as a multitester.
To measure voltage, you need to set the multimeter to measure voltage. This is usually indicated by a "V" with a straight line next to it, which indicates DC voltage. If you are measuring a voltage less than 20V, you should turn the knob to the 20V setting. This will allow you to read from 2.00 to 19.99.
Once the multimeter is set to measure voltage, you can insert a probe into each slot of the outlet and read the line voltage measurement. A properly working outlet gives a reading of 110 to 120 volts. If there is no reading, you may need to check the wiring and the outlet.
It is important to note that multimeters are generally not autoranging, so you must set the multimeter to a range that it can measure. For example, if you are measuring a 12V battery, you should use the 20V setting.
When testing an electrical outlet, it is important to work carefully. You should hold both meter probes in the same hand so that a shock does not pass through your body. It is also recommended to turn off the power before beginning any tests.
