There are several ways to transition electrical conduit through a wall. One common method is to use a junction box, which can be recessed into the wall or surface-mounted. The type of junction box used will depend on the specific application and local electrical codes. Another approach is to use a bent section of EMT conduit with a coupling to create a dog leg shape that passes through the wall. It is important to consider the voltage of the circuits, as different voltages may require separate knockouts in the junction box. Additionally, the use of flexible conduit or sleeving may be necessary to make the transition between the conduit and the wall more elegant and code-compliant.
| Characteristics | Values |
|---|---|
| Simplest way | Use an EMT-to-FMC coupling and a length of flexible metal conduit of the same size as your EMT that "dives" into the wall and lands in a straight-in FMC fitting atop the panel |
| Another way | Use a bent section of like-sized EMT and a coupling to make the "dog leg" through the drywall |
| Normal way | Use a box extension with surface mount as any splices have to be accessible |
| Another method | Drill a hole in the drywall and run the conduit through |
| Suggested method | Run the EMT into a 4x4 box while still in the garage, close to the interior wall. Use that box to transition from wires to NM-B, then run NM into the house |
| Alternative method | Use a short piece of EMT to sleeve the NM for the few inches it may run in the garage into the wall |
| Suggestion | Fire-stop caulk or spackle the hole to seal it |
| Another suggestion | Recess an outlet box into a brick wall |
| Another way | Run the cable inside the chimney and do away with the exposed conduit altogether |
| Another suggestion | Keep the box recessed in the wall, drop down in the basement with cable, stub up a piece of conduit on the brick for a surface-mounted box, bring the cable into the conduit with the correct fitting |
Explore related products
What You'll Learn
Using an EMT-to-FMC coupling and flexible metal conduit
Firstly, ensure you have the correct materials. You will need an EMT-to-FMC coupling, which is used to connect the EMT conduit to the flexible metal conduit (FMC). You will also need a length of flexible metal conduit that is the same size as your EMT conduit. Additionally, you may want to use a ground wire to ensure proper grounding.
Next, remove any existing boxes or offset nipples that may interfere with the installation. This step is crucial to ensuring a proper connection. After removing any obstructions, you can then install the EMT-to-FMC coupling. This coupling will allow you to connect the EMT conduit to the FMC. Make sure that the coupling is non-angled and securely fastened, as per electrical guidelines.
Now, you can connect the FMC to the coupling. The FMC should "dive" into the wall and land in a straight-in FMC fitting atop the panel. Ensure that the FMC is securely fastened within 12" of the coupling to maintain stability and comply with electrical codes.
Finally, you can make the necessary connections within the wall. The FMC will likely need to be bent to a 90-degree elbow to meet up with a conduit body or junction box within the wall. It is important to consider pull points along the way due to the number of bends in the conduit. Additionally, ensure that the grounding is adequate, especially if using fittings with thread type mismatches.
