When it comes to electrical wiring, the colours black and white are often associated with polarities. In a standard electrical circuit, the black wire is typically considered hot, carrying power from the source to the device. On the other hand, the white wire is usually neutral, returning the current to the source. However, it's important to note that colour codes and polarities can vary depending on the system. For example, in some cases, black may be negative and red may be positive. Additionally, while black and white wires are commonly associated with AC (alternating current) wiring, DC (direct current) circuits often use red, white, and black wires, with red carrying positive voltage and black serving as circuit ground. Understanding the basics of electrical circuits and colour-coding is essential for safety and avoiding mistakes, especially when performing DIY electrical projects.
| Characteristics | Values |
|---|---|
| Black wire in AC power | Positive or live wire |
| Black wire in DC power | Negative |
| White wire in AC power | Neutral or negative |
| White wire in DC power | Ground or neutral |
| Red wire in AC power | Positive or live wire |
| Red wire in DC power | Positive |
| Green wire | Ground |
| Copper wire | Positive |
| Silver wire | Negative |
| Blue wire | Phase 3 "hot" wire |
| Extension cord with positive wire | Smooth |
| Extension cord with negative wire | Ribbed or grooved |
