Electrical components are the basic parts of an electronic system that processes information in the form of electrical signals. They are used to affect electrons or their associated fields. Electrical components can be classified as passive, active, or electromechanical. Passive components, such as resistors, capacitors, inductors, and transformers, cannot introduce net energy into a circuit and rely solely on the power available from the circuit they are connected to. Active components, on the other hand, can introduce energy into a circuit, with batteries being a prime example. Electromechanical components, such as relays and switches, carry out electrical operations using moving parts or electrical connections. Integrated circuits, or chips, are unique electrical components that integrate multiple electrical components, such as transistors, resistors, capacitors, and diodes, into a single unit. These chips are essential in powering modern electronic devices. Other examples of electrical components include wires, LEDs, transistors, crystals, and fuses.
| Characteristics | Values |
|---|---|
| Purpose | To change electrical energy into other forms of energy, such as in HVAC systems |
| Types | Passive, Active |
| Passive Components | Resistors, Capacitors, Inductors, Transformers |
| Active Components | Voltage and Current Sources |
| Functions | Amplify, Switch, Generate Electrical Signals |
| Examples | Recloser, Arc-Fault Circuit Interrupter, Network Protector, Magnetic Starter, Sensors, Transducers, Conductors, Switches, Fuses, Diodes, LEDs, Transistors, Crystals, Relays, Connectors, Integrated Circuits |
| Structure | Printed Circuit Board |
| Printed Circuit Board | A skeletal structure that holds electronic components together and provides pathways for information flow through PCB traces |
| PCB Traces | Metal wires, usually copper strips, sometimes aluminium or silver |
| PCB Material | Insulator material (dielectric), typically fiberglass impregnated with resin |
| Mounting Techniques | SMT (Surface Mount Technology), Through-Hole |
Explore related products
$14.59 $24.99
What You'll Learn
- Resistors, capacitors, inductors, transformers, and diodes are passive devices
- Active components include voltage and current sources
- Transducers and sensors convert physical data into electrical impulses
- Integrated circuits are unique, combining multiple electrical components
- Conductors, switches, and fuses are standard electrical components
Resistors, capacitors, inductors, transformers, and diodes are passive devices
Resistors are electrical components that resist the flow of electricity or electric current. They cause a drop in voltage and radiate heat. Resistors are used to regulate the flow of current in electronics and certain electrical applications. For example, a common electric cooktop burner is a resistor.
Capacitors store electrical energy in the form of a charge on two plates that are insulated from each other but are in close proximity. They are used for filtering power supply lines, tuning resonant circuits, and blocking DC voltages while passing AC signals. In conjunction with resistors, capacitors can form RC (resistor-capacitor) networks, which are used in filtering, DC blocking, decoupling, and coupling phase-shift circuits.
Inductors are components that demonstrate inductance, which means they induce an electromagnetic field in the space around a conductor. The electromagnetic field is stored energy, which the inductor can later return as a current. Inductors generate magnetic fields when current flows through them, and they resist changes in current. They freely pass DC current but impede the flow of AC current.
Transformers are used to transform voltages from one level to another. They do this by converting electrical energy to magnetic energy and then back into electrical energy in a coil with a different number of turns.
Diodes are semiconductor devices that can be used for voltage regulation, such as in Zener diodes. Light-emitting diodes (LEDs) are a prominent example of optoelectronic devices, which convert electrical signals to optical signals and vice versa.
