Electrical wiring colour codes are used to aid the identification of individual wire phases and to indicate how power moves within circuits. These colour codes vary depending on the region and the type of wiring. For example, the UK and Europe use green for the earth wire, blue for the neutral wire, and brown for the live wire, while the US uses green or green with a yellow stripe for the protective ground, white or grey for the neutral wire, and black or red for the live wire. Understanding these colour codes is essential for safety, as incorrectly identifying wires can lead to accidents, power outages, and electrical incidents such as fires.
| Characteristics | Values |
|---|---|
| Protective ground wire colour | Bare, green or green-yellow striped |
| Hot (active) wire colour | Any colour except protective ground wire colours; commonly black, red, or white with red or black tape |
| Neutral wire colour | Blue |
| Live wire colour | Brown |
| Earth wire colour | Green and yellow |
| Three-phase electricity supply wire colours | Black, red, and blue (208 VAC); brown, orange, and yellow (480 VAC) |
Explore related products
What You'll Learn
Wire colour coding standards vary across countries
Wire colour coding standards are not uniform across the world. While there are international wire colour codes, some countries have their own standards. For instance, the US follows the National Electrical Code (NEC), which is identified as NFPA 70 as it is sponsored by the National Fire Protection Association. The NEC is reviewed, amended and updated by its authors every three years, with the latest update in 2020. The US National Electrical Code mandates that the grounded neutral conductor of a power system be white or grey. Black, red, and blue are used for 208 VAC three-phase, while brown, orange and yellow are used for 480 VAC. Conductors larger than #6 AWG are only available in black and are colour taped at the ends.
Canada also has its own wiring standards, governed by the Canadian Electric Code (CEC). The protective ground is green or green with a yellow stripe, the neutral wire is white, and the hot (live or active) single-phase wires are black, with a second active in red.
In the UK, wiring colours were changed to harmonise with European cable colours for consistency and to avoid confusion. The old UK black neutral wire was replaced by a blue neutral wire, and the old red live wire was replaced by a brown live wire. The UK and Europe's earth wire cable colour is green, and the neutral wire cable colour is blue.
Australia also has a different wiring colour standard.
