Electrical schematics are a type of map that outlines the functionality of an electric circuit, providing a basis for assembly, troubleshooting, and system design. They are comprised of symbols, wires, and component designators. The symbols are the building blocks of any electrical schematic and can represent anything from ground points to different types of currents. Wires are shown as lines connecting the components, with colours indicating their purpose. Component designators are usually a combination of letters and numbers that denote the type of electrical or electronic component. While these designators are standardized, they are not always consistent.
Explore related products
What You'll Learn
Letters denote component type
On a schematic diagram, letters and numbers are used to identify the various components, their relationships, and the specifics of the PCB circuit design. These letters are standardized so that engineers and technicians across the world can easily understand the schematic.
Component designators are typically a letter or combination of letters that denote the type of electrical or electronic component. For example, R denotes a resistor, C denotes a capacitor, L denotes an inductor, D denotes a diode, and U denotes an integrated circuit. These letters are combined with numbers to create unique identifiers for each component on a schematic. For example, R1, R2, and R3 could represent three different resistors in the same circuit.
While these letter designations are standardized, there may be some variations in different regions or industries. For example, the IEC (International Electrotechnical Commission) and the IEEE (Institute of Electrical and Electronics Engineers) have different sets of symbols for the same component. Additionally, some components may have non-literal prefixes, such as L for inductors, as the current has already taken the letter I.
Letters are also used to identify the connecting leads or pins of a component in a schematic diagram. For instance, the connecting leads of a bipolar junction transistor (BJT) are identified as E (emitter), B (base), and C (collector).
In addition to letters, graphical symbols are used to identify the type of electrical element, whether it is resistive, inductive, capacitive, or mechanical. These symbols, along with lines representing wires or component leads, show how the components are electrically connected in the circuit.
