The term 1-gang is used to refer to the width of an electrical box and the corresponding width of the cover plate. In other words, a 1-gang box is wide enough to fit only one switch or outlet. The term gang is also used to refer to the number of switches or outlets that can be accommodated by an electrical box. In the UK, the term gang is used to refer to the number of circuits in the context of switches, but physical size in the context of boxes.
Characteristics and Values of a 1-Gang Electrical Box
| Characteristics | Values |
|---|---|
| Definition | A 1-gang electrical box is wide enough to fit one switch or duplex receptacle. |
| Switches | 1-gang boxes have one switch button. |
| Circuits | A 1-gang box can control a single lighting circuit. |
| Plates | A 1-gang plate is the same size as a 1-gang socket. |
| Usage | 1-gang boxes are used for single switches or outlets. |
| International Meaning | Outside the US, "gang" refers to the number of circuits in a box, not its physical size. |
Explore related products
What You'll Learn
Gang refers to the width of the box
When discussing electrical boxes, the term "gang" refers to the width of the box and, consequently, the width of the cover plate. The number of "gangs" indicates how many standard switches or receptacles the box can accommodate. A single-gang or 1-gang box is wide enough for one switch or outlet, whereas a two-gang or 2-gang box can accommodate two devices side by side.
In the United States, "gang" typically refers to the physical size of the circuit box. Switches and receptacles usually conform to a standard width, so the number of "gangs" corresponds to the quantity of these standard components that can fit within the box. This terminology is also used in the UK, but with some variations due to the larger size of UK plugs, which are not typically stacked.
It is important to note that the term "gang" can have different meanings in other contexts. For example, it can refer to the number of circuits within a single box, irrespective of its physical size, especially in international usage. Additionally, "gang" can also refer to a group of tools used for a specific project or a group of workmen and their materials.
